CAME 806SL-0170 User Manual

will be saved: from (1) to (25) + (#). 󱵤
- Enter 4 + (#)
- Send the code from the transmitter that is
already memorized in the operator (within 10
s). ❼
- Waitfor the sound signal
Using the internal Rolling
Code radio-frequency code
BASIC procedure
The position in the memory and the radio-
frequency code are processed automatically
(Four USER COMBINATIONS, maximum).
- Enter the INSTALLER PASSWORD + (#)
- Enter 3 + (#)
- Enter a USER COMBINATION (from two to
eight figures) + (#)
- Repeat the USER COMBINATION + (#)
- Waitfor the sound signal
- Save the radio-frequency code into the
operator.
ADVANCED procedure
The position in the memory and the radio-
frequency code need to be entered manually
(25 USER COMBINATIONS, maximum).
- Enter the INSTALLER PASSWORD + (#)
- Enter 4 + (#)
- Enter a USER COMBINATION (from two to
eight figures) + (#)
- Re-enter the USER COMBINATION + (#)
- Specify the position in the memory where it
will be saved: from (1) to (25) + (#). 󱵤
- Enter 1 + (#)
- Select the code: 1 (or 2, 3, 4) + (#)
- Waitfor the sound signal
- Save the radio-frequency code into the
operator.
Using the internal, fixed
radio-frequency code
- Enter the INSTALLER PASSWORD + (#)
- Enter 4 + (#)
- Enter any USER COMBINATION of two to
eight fi gures + (#)
- Re-enter the USER COMBINATION + (#)
- Specify the position in the memory where it
will be saved: from (1) to (25) + (#). 󱵤
- Enter 2 (12 bit) / 3 (24 bit) + (#)
- Select code 1 (or 2, 3, 4) + (#)
- Wait for the sound signal
- Save the radio-frequency code into the
operator.
Other settings
Edit INSTALLER PASSWORD
- Enter the INSTALLERPASSWORD + (#) + 1 +
(#)
- Enter the new password + (#) (three to eight
fi g u r e s )
- Re-enter the new password + (#)
- Wait for the sound signal
Restoring factory settings
- With one hand, hold down both control cards,
and with the other remove the battery
- press and keep pressed the (#) key
- fi t the battery and wait 5 seconds for the
sound signal
Restoring the 555 installer password
- With one hand, hold down both control cards,
and with the other remove the battery
- press and keep pressed the (*) key
- fi t the battery and wait for the sound signal
(about 5 seconds)
Editing USER COMBINATIONS
- Press (*) + (#)
- enter the USER COMBINATION + (#)
- enter the new USER COMBINATION + (#)
- re-enter the new USER COMBINATION + (#)
- wait for the sound signal
Removing users
- Enter the INSTALLERPASSWORD + (#) + 7 +
(#)
- enter the position between 01 and 25 + (#)
- repeat the position + (#)
- wait for the sound signal
Removing ALL users
- Enter the INSTALLERPASSWORD + (#) + 7 +
(#)
- enter 00 + (#)
- repeat 00 + (#)
- wait for the sound signal
Saving on Memory Roll (if fitted)
- Enter the INSTALLERPASSWORD + (#) + 5 +
(#)
- wait for the sound signal
Restoring from Memory Roll (if fitted)
- Enter the INSTALLERPASSWORD + (#) + 6 +
(#)
- wait for the sound signal
System options
- Enter the INSTALLERPASSWORD + (#) + 0 +
(#)
- press the key of the function you want (see
table) + (#)
- set the value you want (see table) + (#)
- wait for the sound signal
Key Function Value
2
Block for 1
minute (after
five errors)
0 = OFF /
1 = ON (default)
3LED brightness
1, 2, 3 (default),
4, 5
4
Activating the
backlighting
0 = OFF /
1 = ON /
2 = press any key
for three seconds
(default)
5
Transmitting
power
0 = 0 dBm /
1 = 5 dBm /
2 = 7 dBm
(default) /
3 = 10 dBm
Replacing the battery
Battery ALMOSTflat: Three flashes from the
LED any time a key is pressed. With backlighting
on: only the center LED turns on.
Flat BATTERY: the LEDs flash three times
and the sound signal sounds off three times,
simultaneously. - The keypad is no longer
usable.
- Strip the frame
- With one hand, hold down both control cards,
and with the other remove the battery; replace
the battery with the right type and respect the
polarities shown on the control card. 󱵥❹.
Legislative references
This product complies with the applicable
standards in force at the time of manufacturing.
RED - CAME S.p.A. declares that the product
described in this manual complies with Directive
2014/53/EU and the Radio Equipment Regulations
2017.
The full EC declaration of conformity and UK
Conformity Assessed (UKCA) marking information
can be found at www.came.com.
DISMANTLING AND DISPOSAL - The
packaging materials (cardboard, plastic,
and so on) should be disposed of as solid
household waste. Separate and properly
dispose of the device components, that is,
metals, control boards, batteries, and so on.
Check your local laws to properly dispose of
the materials.
DISPOSE OF RESPONSIBLY!
THE CONTENTS OF THIS MANUAL MAY BE
CHANGED AT ANY TIME WITHOUT PRIOR
NOTICE.
THE MEASUREMENTS, UNLESS OTHERWISE
STATED, ARE IN MILLIMETERS.
