ENGLISH
General Precautions
• Before installing, carefully read the
instructions and follow the process
explained by the manufacturer. •
Installing, programming, commissioning
and maintenance of this device must be
only done by qualified, specifically trained
technicians, and in full compliance with any
applicable regulatory provisions, including
workplace safety and waste disposal
standards and regulations. • Before carrying
out any cleaning or maintenance operation,
disconnect the device from the power
supply. • The equipment must be destined
solely for the use for which it was expressly
designed. • The manufacturer can not be
held liable for any damage resulting from
improper, unreasonable, and/or erroneous
use. • Install in state-of-the-art fashion, so
that the casing remains clean and watertight.
• The product, in its original packaging
supplied by the manufacturer, must only be
transported in a closed environment (railway
carriage, containers, closed vehicles). • If
the product malfunctions, stop using it and
contact customer services at https://www.
came.com/global/en/contact-us or via the
telephone number on the website.
The manufacture date is provided in
the production batch printed on the product
label. If necessary, contact us at https://
www.came.com/global/en/contact-us.
The general conditions of sale are given in
the official CAME price lists.
Description
Radio-frequency, 433.92 MHz SELT1W4G and
868.35 MHz SELT1W8G surface-mounted
keypad selector, featuring 25 savable USER
COMBINATIONS, and installer password for
accessing the programming mode.
Compatible with fixed-code CAME transmitters
and TW-EE.
Description of parts
① Casing
②Gasket
③ Inner frame
④ Keypad
⑤Fastening screws
⑥Front cover
⑦ Memory Roll Card
⑧ Battery
Dimensions (mm)
Technical data
Type
SELT1W4G /
SELT1W8G
Protection rating (IP) 54
Power supply (V)
3 (one CR123A
battery for a
minimum of
1600mAh).
1
Maximum draw (mA) 48
Maximum
consumption (mW)
144
Range in open field
(m)*
0.5 min.
80 max.
USER COMBINATION
fi gures
2 min. - 8 max.
Figures
INSTALLER
PASSWORD
3 min. - 8 max.
Number of
combinations
111,111,100
Operating temperature
(°C)
-20 to +55
Storage temperature
(°C)**
-25 to +70
Average life (hours)*** 100,000
Apparatus class III
(*)⚠ if the keypad is installed onto metal parts,
the range will decrease.
(**) Before installing the product, keep it at
room temperature where it has previously been
stored or transported at a very high or very low
temperature.
(***) The average product life is a purely
indicative estimate. It applies to compliant
usage, installation and maintenance conditions.
It is also influenced by other factors, such as
climatic and environmental conditions.
1
Average battery life: 24 months with
backlighting on / 48 months with backlighting
off.
Installing
Drill the holes marked on the back of the
casing. ❶
Fasten the casing by using suitable screws and
plugs. ❷
Place the gasket and fasten the inner frame. ❸
Fit the battery and fasten the base to the
keypad. ❹
Fit the selector into the casing and fasten it by
using the supplied screws. ❺
Attach the front cover to the selector. ❻
To remove the front cover, use a screwdriver
as a lever.
Operation
The keypad replicates the operation of the
transmitters; the radio-frequency code is
sent by entering a programmable numerical
sequence (USER COMBINATION), followed by
the confi rmation key: # (e.g.: 1932#).
A FIXED-CODE TRANSMITTER CAN EITHER
ACQUIRE A RADIO-FREQUENCY CODE OR USE
THE FOUR INTERNAL CODES (12 BIT, 24 BIT
OR ROLLING CODE).
Entering a wrong code fi ve times in a row, will
block the selector for one minute (this is the
default setting).
To access the programming mode, enter the
INSTALLER PASSWORD (the default one is
555#).
The 555 numerical sequence cannot be used
as a USER COMBINATION.
During programming, the backlighting is
intermittent.
The (*) key CANCELS any procedure that is
underway.
The INSTALLER PASSWORD and the USER
COMBINATION must be di erent.
Pressing any key for three seconds will activate
the backlighting.
The BASIC procedure uses the fi rst 4 memory
locations of the USER COMBINATION.
⚠ When the memory is full, the device
emits four consecutive sound signals.
Self-learning from a fixed-code
transmitter
BASIC procedure
The position in the memory is automatically
managed by the system - there are up to FOUR
USER COMBINATIONS available.
- Enter the INSTALLER PASSWORD + (#)
- Enter 2 + (#)
- Enter a USER COMBINATION (from two to eight
figures) + (#)
- Repeat the USER COMBINATION + (#)
- Send the
code from the transmitter that is
already memorized in the operator (within 10
s). ❼
- Waitfor the sound signal.
ADVANCED procedure
The position in the memory needs to be
manually entered - there are up to 25 USER
COMBINATIONS.
- Enter the INSTALLER PASSWORD + (#)
- Enter 4 + (#)
- Enter a USER COMBINATION (from two to
eight figures) + (#)
- Repeat the USER COMBINATION + (#)
- Specify the position in the memory where it
Page 6 - Manual FA01690M4A - 06/2022- © CAME S.p.A. - Translation of the original instructions
The contents of this manual may be changed, at any time, and without notice.
