Description
Device for managing Rio-series accessories via radio (max. 10
units).
Main control-card components
③ Antenna
④ Buzzer
⑤ Radio power selector dBm (L=5 / H=10)
⑥ Alert LED
⑦ Programming button
⑧ RESET button
⑨ Flashing-light input
⑩ Terminals for connecting to the control panel (see fi gure )
Technical data
Type RIOCT8WS
Power supply (V) 24 AC/DC
Current draw (mA) 80 max.
Relay contacts 24 V max. (A) 1
Radio range over clear areas (m) 30 max.
Frequency (MHz) 868.95
Installing
⚠ Before continuing, cut o the MAINS POWER SUPPLY and dis-
connect any batteries.
Fitting the casing and control card
- Use a drill to perforate the marked holes needed for the cables to
pass through ①.
- Fasten the casing, using plugs and screws suitable for the surface.
- Fit the card and slide it along its guide.
NB: Do not change the antenna's position.
- Once the cables are laid (see example in figure C), power up the
automation and check that the WIRELESS LEDs are fl ashing. If they
are not fl ashing, RESET the card (see the corresponding procedure).
- Remove the batteries from the accessories.
- Save each and every component of the system (see accessories
instructions).
Make the required functional checks (see the corresponding proce-
dure), close the cover and fasten it to the base by using the supplied
screw. ②.
Description of the terminal board
10-2
Power supply input 24 V AC/DC ⑬
10-E
Flashing light input 24 V AC/DC ⑭
TS Safety-test input
(if unused, bridge with 2) ⑯
IN1 - IN2 Not used
OUT1 (NC) Output activated by IN1 input on the RIOED8WS
saved with T1
OUT2 (NC) Output activated by IN2 input on the RIOED8WS
saved with T2
OUT3 (NC) Output activated by RIOPH8WS saved with T1
OUT4 (NC) Output activated by RIOPH8WS saved with T2
OUT5 (NC) Not used
LAMP-230 V
Flashing light input at 230 V ⑮
