CAMON TC07 Turf Cutter Tracmaster Ltd
_______________________________________________________________________________________________
6 For parts diagrams visit www.tracmaster.co.uk
4.5 Drive Lever
The drive lever is located beneath the left hand handlebar grip.
This lever operates both the cutting blade and the driving power to the back wheels. It does
this by raising the engine speed until a centrifugal clutch engages and transfers the engine
power to the driven components of the TC07.
Letting go of the drive lever causes the engine revolutions to drop, the centrifugal clutch to
disengage and both the engine drive and cutting blade to stop moving.
4.6 Cutting Depth Adjustment
The cutting depth of the blade is adjusted using the two adjuster knobs, the lower locking
knob and the top height adjustment knob. The top height adjustment knob is connected to
a length of threaded rod that is wound into and out of the chassis. These knobs are located
in front of the handlebar mounting on the top section of the main chassis.
The lower knob is for locking the position of the top knob. To adjust the depth of the cutting
blade, first loosen the lower locking knob. Once this knob is able to move freely, you can
adjust the position of the top knob into and out of the chassis by turning it clockwise and
anticlockwise.
Using the indicator sticker on the thread of the top knob it is possible to choose your
required depth of cut. This ranges from 25mm to 40mm.
4.7 Machine Lifting Lever
Located at the rear of the machine, beneath the handlebars, this lever allows the operator
to move the cutting blade in and out of the ground.
4.8 Commissioning
Prior to operation it is necessary to check engine oil level and add engine oil to the level
indicated in the specification table on page 4.
The engine fuel tank will not contain fuel so will need filling to the recommended level
before use.
4.9 General Safety Instructions
Be aware of all the safety requirements for the machine.
Visually check the machine for operational safety, complete components and fixed
guarding prior to each use.
Read and be aware of the warning and instruction signs located on the machinery.
Cordon off the work area to access from the general public.
