33
Item Part Number Description Quantity
1 PG24SG-5 Upper Grate 2
2 PG24-70 Lower Grate 2
3 PG24WWSB-2 Vent 2
4 PG24LS-8 Lid Hinge 2
5 PG24WWSB-3 Vent Cover 1
6 PG24-54 Probe Cover 1
7 PG24SG-11 Grate Bracket 2
8 PG24-44 Thermometer 1
9 PG24WWSB-4 Thermometer Bracket 1
10 PG36SGX0-1 Cover Plate 1
11 PG24CL-2 Hopper Assembly 1
12 PG24WWSB-5 Valve Handle 1
13 PG24WWSB-6 Valve Spring 1
14 PG24WWSB-7 Hardware Kit 1
15 PG24WWSB-8 Valve 1
16 PG24WWSB-9 Set Screw 1
17 PG24WWSB-10 Back Left/Front Right Leg 2
18 PG24WWSB-11 Leg Bracket 2
19 PG24WWSB-12 Front Left/Back Right Leg 2
20 PG24WWSB-13 Caster 4
21 PG24WWSB-14 Drip Tray 1
22 PG24WWSB-15 Lid Insulation 1
23 PG36CL-1 Side Shelf 1
Item Part Number Description Quantity
24 PG24WWSB-16 Grease Catch 1
25 PG24WWSB-17 Smoke Box Exterior Insulation 1
26 PG24WWSB-18 Smoke Box Interior Insulation 1
27 PG24WWSB-19 Smoke Box Cover Plate 1
28 PG24WWSB-20 Smoke Box Slide Bolt 2
29 PG24WWSB-21 Smoke Box 1
30 PG24WWSB-22 Smoke Box Handle 1
31 PG24WWSB-23 Smoke Box Cosmetic Plate 1
32 PG24WWSB-24 Smoke Box Slide 1
33 PG24-9 Knob 2
34 PG24-42 Ash Cleanout Lock 1
35 PG24WWSB-25 Shoulder Nut 1
36 PG24WWSB-26 Cotter Pin 1
37 PG24-41 Ash Cleanout Plate 1
38 PG24-11 Grease Bucket 1
39 PG24WWSB-27 Heat Deflector 1
40 PG24-57 Handle 1
41 PG24-71 Bezel 2
42 PG24-59 Shoulder Bolt 2
43 PG24WWSB-28 Grill Lid 1
44 PG24-17 Ash Cup 1
45 PG24WWSB-29 Bottom Shelf 2
REPLACEMENT PARTS MODEL PG36WWSB
2
3
5
7
4
6
8
9
10
11
17
18
19
42
41
40
43
44
45
20
21
22
23
24
25
26
27
28
29
30
31
32
39
38
37
35
34
33
36
12
13
14
15
16
1
46
