CAMPAGNOLO Ekar RD21 - Page 7

REPLACING THE JOCKEY CAGE - Rev. 01/ 06-2021 CAMPAGNOLO COMPONENTS - TECHNICAL MANUAL
7
1) Insert the sealing ring, making sure it is
positioned correctly (Fig.1).
2) Apply “Loctite 2701” (Fig.2) to the clutch
shaft.
3) Install the jockey cage, hooking the spring
in the corresponding hole on the jockey
cage itself (Fig. 3).
4) Install the nut on the jockey cage side by
acting on the clutch shaft (Fig. 4).
Using a T15 Torx wrench, tighten to a torque
of 8 Nm (Fig.5).
Fig.1
Fig.2
Fig.3
Fig.4 Fig.5
T15
8 Nm
