Operating Instructions and Parts List PW1805
8
www.chpower.com
1. The lance is affected by pressure during
operation; therefore hold it firmly with
both hands and point the nozzle
toward the ground.
2. Activate by pulling the trigger of the
gun/spray handle.
3. Adjust the distance to the cleaning sur-
face, which will also adjust your pres-
sure of the nozzle.
4. Spray pattern shape and intensity can
be changed by twisting the spray
adjuster at the end of the lance. Keep
hands clear of the front of the lance to
prevent injury. See figure 7.
Operation
Notes
Figure 7 - Spray Adjust
END OF OPERATION
1. Press the ON/OFF switch to “OFF” on
the pressure washer.
2. Disconnect the plug from the power
source.
3. Shut off the water supply.
4. Activate the spray handle to relieve the
machine of pressure.
5. Lock the trigger into the “OFF”
position.
