Campbell Hausfeld PW2120 Assembly Instructions And Replacement Parts Manual

5
PW2120, PW22221, PW2458
Ref.
No. Description PW2120 PW2221 PW2458 Qty.
1 Handle/Placard assembly PM060020SJ PM060020SJ PM236000SJ 1
2 1/4-20 x 1.75 Hex head bolt* PM001903AV PM001903AV PM001903AV 5
3 1/4-20 Nylock nut* ST073808AV ST073808AV ST073808AV 11
4 Flatwasher, 1/4-20* PM002000AV PM002000AV PM002000AV 18
5 Hose Rack PM223700AV PM223700AV PM223700AV 1
6 Gun Rack PM033410AV PM033410AV PM033410AV 1
7 10-24 x 1.75 Socket head cap screw* MJ103803AV MJ103803AV MJ103803AV 2
8 10-24 Nylock Nut* ST073803AV ST073803AV ST073803AV 2
9 Flatwasher, 10-24* ST070906AV ST070906AV ST070906AV 6
10 Baseplate PM223200AV PM223200AV PM235700AV 1
11 Leg, right side PM223610BH PM223610BH PM223610BH 1
12 Leg, left side PM223620BH PM223620BH PM223620BH 1
13 Axle PM224501BH PM235601BH PM235601BH 1
14 1/4-20 x 2.25 Hex head bolt* MJ101104AV MJ101104AV MJ101104AV 2
15 Wheel WA005100AV WA004900AV WA004900AV 2
16 Hub Cap◆ PM224400AV N/A N/A 2
17 Push nut MJ104700AV AL066300AV AL066300AV 2
18 Rubber bumper AL062300AV AL062300AV AL062300AV 2
19 1/4-20 x .75 Self tapping screw* MJ102100AV MJ102100AV MJ102100AV 2
20 Engine PM004050AV PM004100AV PM041902AV 1
21 Pump Assembly** PM041810SJ PM004610SJ PM041803SJ 1
22a Gun PM005133AV PM005133AV PM005133AV 1
22b Gun o-ring◆ PM232210SV PM232210SV PM232210SV 2
22c Gun back-up o-ring◆ PM232211SV PM232211SV PM232211SV 1
23 Lance PM035150AV PM005116AV PM035140AV 1
24 Hose PM012904AV PM005001AV PM005001AV 1
25 Detergent tube and filter PM013800AV PM013800AV PM013800AV 1
26 Front guard N/A N/A PM080830AV 1
27 1/4-20 X .75 Self tapping screw blk* N/A N/A MJ106206AV 4
* Item available at local hardware store
** See separate pump breakdown sheet for replacement pump parts.
** * Components not included with handle/placard assembly (ref #1)
****Available only on model PW2458
◆ Item not shown
Replacement Parts List
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
Address parts correspondence to:
The Campbell Group
Attn: Parts Department
100 Production Drive
Harrison, OH 45030 U.S.A.
www.chpower.com
