23
MAINTENANCE
WHEEL SHAFT LUBRICATION
Apply evenly 1 to 1.5 cc of grease on the wheel
shaft, over the entire circumference (360°) and
width.
REFERENCE “B”
LUBRICATION - WHEELS & BEARINGS
Camso recommends pouring 5 cc of oil under
wheel caps and between the two wheel bearings,
at every maintenance interval. This will help
minimize presence of contaminants and extend
wheel bearing life.
Unbolt wheel from frame and carefully remove
exterior bearing seal (1) of both bearings. Clean
off old lubricant and pack with new grease. Lastly,
re-install seals over matching bearings.
CAUTION: Take special care to avoid damaging the
bearing seals when you remove and reinstall them.
REFERENCE “C”
HUB BEARING SEAL LUBRICATION
Apply evenly 1.5 to 2 cc of grease between the
hub seal lips and on its the entire circumference
(360°).
IMPORTANT: The hub seal must be installed
flush with the hub face.
CAUTION: Replace hub seal immediately if
defective.
