SPARE PARTS - FL17XX
The column "Pos." refers to the exploded drawing "type FL17XX" on page 26.
PZ VERSION - PIEZOELECTRIC LIGHTING
part number pos.
component
2000008 4
Hinge for glass lids
3000078 3
Single glass for FL1770 - FL1780
3000447 3
LH glass for FL1765
3000448 3
RH glass for FL1765
3000450 3
LH glass for FL1766
3000449 3
RH glass for FL1766
3000083 23
High rubber bushing for pan holders
3000073 1
Wire pan holder for AUX burner
3000074 1
Wire pan holder for SR burner
4000026 30
2nd series lid stud bolt
4000170 2
Glass lid cable gland
4000224 8
Polyethylene intense black screw cap 2.5 / 12 mm
4000008 24
Standard black knob
4000031 29
Universal nut for thermocouple
4000069 29
Thermocouple for fast-on magnet cock
4000025 20
Burner spreader for 2nd series AUX burner
4000021 21
Ø 55 perforated and enamelled cover 2nd series AUX burner
4000024 18
Burner spreader for 2nd SR semirapid burner
4000019 19
Ø 75 perforated and enamelled cover 2nd series SR burner
4000062 22
Countersunk flat head screw + M2.5 x 20 DIN EN ISO 7046 GV
4000223 9
PZD perforated head chipboard screw
7000138 -
Glass lid flame label
4000253 27
Short piezo igniter 15 x 1.5 mm
4000232 28
Burner lighting glow plug L 350
4000137 28
Clip for glow plug
4000034 -
Earth cable
IGN VERSION - ELECTRONIC LIGHTING
part number pos.
component
4000319 -
Single-pole button 3A red key
2000147 -
12V generator kit + assembly bracket
4000168 -
Universal lighting cable (-)
4000169 -
IGN lighting cable L320
4000297 -
IGN lighting cable 2 (+)
4000232 -
Burner lighting glow plug L350
4000137 -
Clip for glow plug
