What to do if a CanadianSolar CSI-5K-S22002-E malfunction impairs safety?
If a malfunction impairs the CanadianSolar Inverter's safe operation, it must be repaired immediately before restarting the inverter. Please contact local authorized personnel if any service work is required.
How to prevent damage when servicing a CanadianSolar CSI-5K-S22002-E?
To prevent damage when servicing a CanadianSolar Inverter: Use only accessories and spare parts approved by the inverter manufacturer. Never modify the inverter or other components of the inverter, as doing so may result in the loss of warranty rights.
How to safely service a CanadianSolar Inverter to avoid injury?
To safely service a CanadianSolar Inverter and avoid injury, remember that the inverter is powered by both the PV array and the utility grid. Before any service work: 1. Disconnect the inverter from the utility grid first, and then from the PV array. 2. Wait at least 5 minutes after shutting down the inverter to allow the inner capacitors to discharge completely. 3. Verify that there is no voltage or current present using appropriate testing devices.
General| Model | CSI-5K-S22002-E |
|---|---|
| Type | String Inverter |
| Rated Output Power | 5000 W |
| Max. DC Power | 7500 W |
| Max DC Input Voltage | 1000 V |
| Start Voltage | 200 V |
| Number of MPPT | 2 |
| Efficiency | 98.2% |
| Dimensions | 460 x 380 x 160 mm |
| Weight | 17.5 kg |
| Cooling | Natural Convection |
| Protection Class | IP65 |
| Nominal AC Power | 5000 W |
| Max. AC Apparent Power | 5500 VA |
| Max. Output Current | 22 A |
| Nominal Frequency | 50/60 Hz |
| Total Harmonic Distortion | <3% |
| DC Connection | MC4 |
| Operating Temperature Range | -25°C to +60°C |
| Cooling Method | Natural Convection |
| Max. AC Output Current | 22 A |
| Frequency | 50/60 Hz |
| Max. Efficiency | 98.2% |
| Nominal AC Voltage | 220 V / 230 V / 240 V |
| AC Voltage Range | 180 ~ 280 V |
| AC Output Voltage | 220 V / 230 V / 240 V |
| Power Factor | >0.99 |
Emphasizes reading and following all safety instructions, cautions, and warnings in the manual.
Outlines essential requirements for installing the inverter, including location, clearances, and environmental conditions.
Provides step-by-step instructions for installing the wall-mounting bracket, including drilling and fixing procedures.
Details the steps for hanging and securing the inverter onto the installed wall-mounting bracket.
Highlights critical safety warnings regarding lethal voltages and electrostatic discharge during electrical work.
Provides guidelines for wiring the AC output, including circuit breaker selection and cable connection procedures.
Details the process for wiring the DC input, including connector assembly and precautions.
Provides detailed steps for stripping, crimping, and inserting DC connectors for proper wiring.
Details essential electrical checks, including PE connections, voltage, polarities, and insulation.
Explains the step-by-step procedure for starting up the inverter after inspections, including operating statuses.
Guides on setting inverter parameters, including country selection, power quality response modes, and protection.
Outlines the safe procedure for turning off the inverter, emphasizing disconnecting power sources first.
Introduces error codes, their meaning, and advises contacting qualified personnel for troubleshooting.
Lists specific error codes (F-100 to F-115) and their corresponding suggestions for resolution.
Lists further error codes (F-116 to F-129) and their corresponding suggestions for resolution.
Guides on configuring the inverter settings via the CSI CloudPro APP to use the CT sensor for export limitation.
Guides on configuring the inverter settings via the CSI CloudPro APP to use the meter for export limitation.
