Basic Structure
W Nmaster2 WX series circuit breakers are available in Drawout & fixed versions. The
drawout version is mounted on a chassis & the fixed version is installed using fixing
brackets.
i
Drawout version
Fixed version
Chassis
Circuit breaker
Front cover
