C&S Electronics WiNmaster 2 - Construction Characteristics; Circuit Breaker Structure and Uniformity

Constructions Characteristics
Performance levels: 50kA (N) 65kA (H)
WX-A WX06A n
WX08A n
WX10A n
WX12A n
WX16A n
WX20A n
WX25A n
U cniform onstruction
… … … . Offering ease for installation and possibility for optimized panel size.
The height and width are showing below for frame WX-A up to 2500A. The panel cutout
size is same for all types of W Nmaster2, which makes it easy to arrange them in
switchboards. Panel cutout for front remains same.
i
The sheet steel structure of WiNmaster 2 is extremely compact, considerably reducing
overall dimensions.
W Nmaster 2 circuit breakers comes in two frame sizes.
WX-A: 630A to 2500A
WX-B: 2000A to 3200A
i
Fixed Type
Drawout Type
8 C&S Electric Limited
9
C&S Electric Limited
Structure of the Circuit Breaker
WX-B WX20B n
WX25B n
WX32B n
Available in both Fixed & Drawout version
W Nmaster 2i
