LED Description

: indicates the fault in L1 phase

: indicates the pickup of Earth over current in Low set

: indicates the fault in L2 phase

: indicates the fault in L3 phase

: indicates the Earth fault for pickup

: indicates the pickup of Earth over current in Hi-set (Stage-1)

: indicates the pickup of Earth over current in Hi-set (Stage-2)

: indicates the pickup of Phase over current Hi-set (Stage-1)

: indicates the pickup of Phase over current Hi-set (Stage-2)

: indicates the pickup of Phase over current Low-set

Ie>

I>>

Ie>>

Ie>>>

I>>>

: indicates the Earth fault for Trip

: indicates the ON condition of the relay

TRIP
