Aux. Voltage Range For H Model 85V-280V AC / 90V-300V DC
For W Model 18V-160V DC
Power Consumption Quiescent approx. 3W Operating approx. <7W
Rated Supply for For H Model 40V-280V AC (Active)
Digital Input 40V-300V DC (Active)
<25V AC/DC (Inactive)
For W Model 18V-150V DC (Active)
<10V DC (Inactive)
Quantity Range Frequency Range Accuracy
Current 0.05 - 30 xIp 50Hz + 2% / + 10mA
Measurement Accuracy
Rated Data Rated current Ip :1A or 5A
Rated frequency Fn : 50 Hz
Drop out to Pickup Ratio >96%
Reset Time 30 mSec
Power consumption At Ip = 1A 0.1 VA
in current circuit At Ip = 5A 0.2 VA
Thermal withstand capability Dynamic current withstand
in current circuit for 1 Sec : 100 x Ip
for 10 Sec : 30 x Ip
continuously : 4 x Ip
Measuring Input
Auxiliary Supply
Front USB Communication
Protocol CSE proprietary protocol: available with front software
Baud rate 19200 bps
Cable reqd. for interface USB cable type (A to A)
08
