Term Blocks Type/Cable Specifications

2 2

Current Inputs Ring Type lug / 2.5mm or 4 mm control cable

2 2

Auxiliary Supply Pin Type lug / 1.5 mm / 2.5 mm control cable

2 2

Rear Comm. Port Pin Type lug / 1.5 mm / 2.5 mm control cable

Front Comm. Port USB, Mini Type - A to A

2 2

Binary Input Pin Type lug / 1.5mm / 2.5mm control cable

Binary Output Pin Type lug / 4.0mm control cable

2 2

Earth Connections Ring Type / 2.5mm or 4 mm contact cable

USB Cable required for Front communication

(Mini - Type A to A)

Recommended Terminal Lugs specifications

Back View of the Relay
