What to do if dishes stop the detergent dispenser from opening in Candy Brava CDPMN 4S622PX/E Dishwasher?
If cutlery, dishes, pans, etc., stop the detergent dispenser from opening in your Candy dishwasher, position dishes so as not to obstruct the dispenser.
Why the wash programme is not thorough enough in my Candy Brava CDPMN 4S622PX/E?
If the wash programme is not thorough enough in your Candy dishwasher, choose a more vigorous programme.
Appliance intended for household, kitchen areas, farm houses, hotels, etc.
Excludes commercial use by expert or trained users.
Appliance for users aged 8+ with limited physical/sensory/mental capabilities.
Not for persons with reduced capabilities or lack of experience unless supervised.
Children must be supervised to ensure they do not play with the appliance.
Children aged 3 and under must be continuously supervised.
Damaged power cord must be replaced by manufacturer or service agent.
Only use supplied hose-sets for water connection; do not reuse old ones.
Water pressure must be between 0.08 MPa and 0.8 MPa.
Ensure carpets do not obstruct base or ventilation openings.
Position appliance after installation so plug is accessible.
Avoid leaving door open horizontally to prevent tripping hazards.
Refer to manufacturer's website for product info and technical data.
Refer to data plate for maximum number of place settings.
Ensure electrical system is earthed, socket compatible, and cables are not crushed.
Avoid using adaptors, multiple plugs, or extension cables.
Appliance must not be supplied via external switching device like a timer.
Unplug appliance and turn off water supply before cleaning/maintenance.
Do not pull power cord or appliance to unplug.
Water may reach very high temperatures during the wash cycle.
Do not expose appliance to rain, sun, etc.
Leaning on open door can cause appliance to tip over.
Do not lift by door; use two people for transport.
Designed for normal kitchen utensils; avoid petrol, paint, chemicals.
No need to add salt if home has water softening device.
Switch off, turn off water, do not tamper. Repair by authorized agent.
To move, lift by top, not bottom of door.
CE marking confirms compliance with EU safety, health, and environmental requirements.
Remove all packaging elements before installation.
Keep packaging materials away from children.
Do not install or use if appliance is damaged.
Follow instructions supplied with the product.
Load sharp utensils with points down or horizontally.
Appliance must be connected using new hose-sets; old ones should not be reused.
Inlet and drain hoses can be directed to left or right.
Dishwasher can connect to cold or hot water up to 60°C.
Flush new or long-unused pipes before connecting to prevent filter clogging.
Water pressure must be between 0.08 MPa and 0.8 MPa.
Connect inlet hose to a tap for water supply shut-off when not in use.
Dishwasher is fitted with a 3/4" threaded connector.
Connect inlet hose 'A' to tap 'B' with 3/4" attachment, ensuring tightness.
Inlet pipe can be extended up to 2.5m using an extension pipe from After Sales Service.
Device blocks water flow/drains excess if levels exceed normal due to malfunctions.
Prevents flooding via sensor activating valve under tap to block water.
If box 'A' (electrical parts) is damaged, unplug immediately.
Connect hose with box 'A' to tap as shown for safety system operation.
Do not cut water supply hose; replace with a longer one if needed.
Stops water flow if tube deteriorates; red mark appears in window 'A'.
Press lock device 'B' to unscrew; replace tube if red mark appears.
Sheath 'B' contains leaks from internal tube 'A' to complete cycle.
Contact Customer Service to replace supply tube after leak detection.
Outlet hose should discharge into a standpipe without kinks.
Standpipe must be min. 40cm above floor, with min. 4cm internal diameter.
Fitting an anti-odour air trap is advisable.
Outlet hose can extend up to 2.5m, max height 85cm. Extension pipe available.
Hose can hook over sink side but must not be immersed in water.
Hose clamp attached to wall highest possible position under worktop.
Check that there are no kinks in the inlet and outlet hoses.
Appearance of white stains on dishes indicates salt container needs filling.
Container for salt is located on the bottom of the machine for softener regeneration.
Use only salt specifically designed for dishwashers to avoid softener damage.
Unscrew cap, refill container, clean residue from threads, retighten.
Some water may overflow; continue adding salt until full.
After loading salt, run a complete wash cycle or a specific rinse program.
Salt dispenser capacity is 1.5 to 1.8 kg and should be refilled periodically.
For first startup, add water to overflow after filling salt container.
If 29-32.5 cm plates used, load onto lower basket after upper is raised.
Turn blocks outwards, remove/remount basket in upper position, replace blocks.
Dishes >20cm or mobile supports cannot be used in upper position.
Dishes >14cm cannot be loaded onto upper basket in models with a third basket.
Remove basket, lift on both sides, and release slowly into position.
Hold basket on both sides, lift gently, then slowly release into position.
Never lift or lower the basket from one side only.
Adjust basket before loading dishes for best results.
Adjustable racks for cups, knives, ladles, and stemmed glasses.
Load saucepans, oven dishes, plates, and bowls into the lower basket.
Load large plates (approx. 26+ cm) slightly tilted towards the rear.
Block plastic bowls on upper basket to prevent overturning from water jets.
Upper basket holds up to 24 plates or 30 glasses.
Foldable racks optimize dish stability and accommodate various sizes.
Example of a standard daily load configuration for the dishwasher.
Load dishes sensibly to ensure the best wash results.
Lower basket has safety stop for safe extraction, useful for maintenance.
Cutlery basket top can be removed for various loading options.
Position cutlery basket correctly by lowering front foldable racks for stability.
Load sharp utensils with points down or horizontally.
Use third basket for cutlery, loading knives with blade down.
Ask for comparison testing and noise level info via email.
Specify model name and number when requesting test information.
Slide or remove side shelves for extra space in upper basket for bulky items.
Use detergent specifically designed for dishwashers (powder, liquid, gel, tablet).
Hand-washing detergents lack proper ingredients and can stop the dishwasher.
Container is inside the door; press button (A) to open.
Close lid by pushing (1) then pressing until it clicks.
Use 20-30g in compartment (B); too little doesn't clean, too much is wasteful.
Ensure lower basket items do not obstruct the detergent dispenser.
Tablets may not dissolve fully in short programs; choose longer ones.
Tablets MUST be placed in the wash section of the detergent container, NOT directly in the tub.
Concentrated detergents with enzymes offer environmental benefits and protect dishes at 50°C.
Place combined detergents in container; empty rinse aid container if using.
Follow manufacturer's instructions; effectiveness depends on water hardness.
Can cause limescale deposits or reduced washing/drying performance.
Problems from combined detergent use are not covered by warranty.
Rinse aid/salt indicator lights are superfluous with TABS; ignore them.
Recommend returning to separate products if washing/drying problems occur.
Refill salt/rinse aid and run load-free cycle after returning to separate products.
Rinse aid helps dishes dry quickly and prevents spots/stains.
Container is to the left of the detergent container (Fig. A "3").
Push reference mark and pull opening tab to open lid.
Check rinse aid level through indicator eye (C) on the dispenser.
Regulator (D) is under lid; recommended position is 4.
Decrease setting for streaks, increase for spots.
System includes central container, micro filter, and flat gauze.
Filters should be checked and cleaned after each wash for best results.
Turn handle anticlockwise to remove filter unit.
Central container is removable for ease of cleaning.
Wash filter under water jet; use small brush if necessary.
Micro filter needs checking every two weeks; check other filters after each wash.
Ensure correct reassembly; poor seating affects efficiency.
Never use the dishwasher without the filters.
Remove food debris, avoid pre-rinsing, soak encrusted dishes, load properly.
Rinse silver immediately, avoid detergent, keep separate from other metals.
Use recommended maximum load size for energy, water, detergent savings.
Use ECONOMY program for light soil; longer programs are generally more efficient.
Avoid thermoplastic, wooden/plastic handles, aluminum, leaded glass.
Test wash one item first to check if decorations fade.
Avoid silver cutlery with non-stainless steel handles due to potential reaction.
Ensure new crockery or cutlery is suitable for dishwasher use.
Leave door ajar after washing for air circulation to improve drying.
Disconnect machine, clean outside with water-soaked cloth; avoid solvents/abrasives.
Tank is self-cleaning; regularly wipe door gasket to remove residue.
Run wash cycle with specialist cleaners to remove deposits; dishwasher must be empty.
Check spray heads on rotor arms are clear if dishes are not washed/rinsed properly.
Remove rotor arms by turning/pushing/unscrewing or pulling; wash under water jet.
Do not use tools that can deform spray heads.
Refit rotor arms in the same position, aligning arrow and screwing into place.
Spots from high iron salts removable with mild abrasive agent.
Turn off water supply and machine by pressing On/Off button after cycle.
Identifies buttons: ON/OFF, REMOTE CONTROL, HALF LOAD, PROGRAMME SELECTION, DELAY START, TABS, SMART DOOR, START/RESET, DISPLAY.
Provides dimensions for free-standing and built-in installation types.
Lists place settings and capacity with pans/dishes for different models.
Details water pressure, fuse, power input, and supply voltage.
Explains information provided on the appliance display during operation.
Details indicators for Temperature, Programme, Time Remaining, Salt, Wi-Fi, etc.
Explains indicator lights for ZOOM, TABS, SMART DOOR, and ADDISH functions.
Touching display during initial seconds can interrupt calibration; unplug and repeat.
Press ON/OFF button for at least 3 seconds to turn appliance on/off.
Connect to power, load dishes, close door, press ON/OFF for 3 seconds.
Select preferred language using SMART DOOR or TABS buttons.
Press START/RESET to accept language selection; WELCOME message appears.
ECO program message appears when SMART DOOR option is activated.
Appliance switches off automatically after 5 minutes if no program is selected.
Adjust parameters: LANGUAGE, SOFTENER, BUZZER, MEMO FUNCTION via Settings menu.
Turn off appliance, then hold ON/OFF and PROGRAMME SELECTION for 5s.
Use SMART DOOR/TABS buttons to adjust selected parameters.
Changing language resets all settings to default factory settings.
Open door, load dishes, select program, enable options, press START/RESET.
Duration shown left of square, temperature right; icons indicate options.
Program starts automatically after door shut and audible signal.
AUTO WASH uses sensor to adapt temperature/time to dish dirtiness for optimisation.
Dirt sensor analyzes water murkiness to adapt cycle parameters for excellent results.
Use impulse washing technology for reduced consumption, noise, and improved performance.
Intermittent pump working is a characteristic of impulse washing, not a malfunction.
Add dishes when ADDISH light is on; appliance stops, time flashes. Close door.
Cycle resumes from where it left off. Do not add dishes after indicator light off.
Opening door during drying cycle produces audio signal; drying cycle not yet finished.
Hold RESET for 3s; program cancels, new one can be set.
Check dispenser for detergent before starting a new program; top up if necessary.
Memory stores selected program; cycle resumes when power is restored.
A 5-second buzzer signals program end (if not muted).
Door opens automatically during drying; wait for end-of-cycle signal.
Extra washing arms activate in specific programs for increased washing force.
Option buttons allow customisation; indicator lights show status.
If an option is incompatible, its indicator light flashes then goes off.
Opens door slightly during/end of drying for natural drying and energy saving.
Do not force shut; ensure free space and wait for opening device.
Enabled in ECO; not available in RAPID 24, ZOOM 39, PREWASH.
Use for few dishes to save water, energy, time; use less detergent.
Optimises combined detergents (3-in-1 etc.); modifies program for best performance.
Recommended for RAPID 24'; extends duration for better tablet performance.
Light indicates salt container needs filling.
Light indicates rinse aid is running out and needs topping up.
Set delayed start time from 00:30 to 23:30 hours.
Press DELAY START, then again to increase delay by 30 mins. Press START/RESET to start.
Hold START/RESET for 3s; program cancels, previous program shown.
Procedure to mute audio signal: hold PROGRAMME SELECTION, switch on, select BUZZER, set to No.
Procedure to set MEMO FUNCTION: hold PROGRAMME SELECTION + ON/OFF, select MEMO FUNCTION.
Procedure: ON/OFF, then PROGRAMME SELECTION + DELAY START for 5s.
If no button pressed, program starts simulating a wash cycle.
Procedure: ON/OFF, then PROGRAMME SELECTION + DELAY START for 5s.
If wash cycle doesn't start, demo mode may not be disabled.
Press TABS + SMART DOOR for 3s to lock keys and prevent accidental changes.
Press TABS + SMART DOOR again, or switch off appliance, to cancel lock.
Memory saves settings during power outage; cycle resumes from where it left off.
Appliance can be remote controlled via a simple app.
Download app, create profile, enroll appliance following app instructions.
App available for Android and iOS tablets and smartphones.
Explore app menus in DEMO mode for Wi-Fi features.
Ensure router is on, smartphone connected to Wi-Fi, and Bluetooth enabled.
Turn on dishwasher by pressing ON/OFF for 3 seconds when instructed by app.
Press PROGRAMME SELECTION/ENROLMENT Wi-Fi for 3s; enrollment status changes.
Enter Wi-Fi password in app and complete procedure; 'CONNECTED' message appears.
'CONNECTED' and 'REMOTE CONTROL' messages appear; Wi-Fi light is steady.
If enrollment fails, 'TRY AGAIN' appears; repeat procedure.
Refer to guide or link for more information on enrollment.
Repeat enrollment, remove product from APP, for problems or router changes.
Fill dishwasher, add detergent, close door, turn on, press PROGRAMME SELECTION/ENROLMENT Wi-Fi for 3s.
Press PROGRAMME SELECTION/ENROLMENT Wi-Fi to exit.
Wi-Fi light flashes slowly, 'REMOTE CONTROL OFF' appears; last program shown.
Wi-Fi light flashes slowly, 'REMOTE CONTROL OFF' appears; remaining time shown.
Hold START/RESET for 3s; cycle cancels, Wi-Fi light flashes slowly.
Press ON/OFF for 3s; cycle pauses, Wi-Fi light flashes slowly.
Opening door disables REMOTE CONTROL; close door to resume.
Explains Wi-Fi light statuses: FIXED ON, SLOW FLASHING, QUICK FLASHING, etc.
Most efficient for energy/water for normally soiled tableware.
For heavily soiled pans and items left all day.
For normal soiled pans and items left all day.
Single cycle for delicate dishes like glassware; quick wash for after meal.
Quick wash for dishes to be washed immediately after meal; load of 6 persons.
Short cold pre-wash for items stored until ready for full load.
Antibacterial cycle for sterilising dishes, babies' bottles etc.
Intended for rapid washing of very dirty dishes.
For everyday dishwashing; two final rinses ensure hygiene.
Fast cycle for normal dishes, optimized by sensor.
Quiet washing cycle, ideal for night use and reduced energy fares.
Suitable for delicate crockery and glassware, less soiled items.
For programs with prewash, add a second dose of detergent directly.
Hardness causes stains; softener unit supplies softened water using salt.
Procedure to set softener based on water hardness (French/German grading).
Turn on, hold PROG SELECTION+ON/OFF, select SOFTENER S4, adjust, switch off.
Softener unit is factory set at level 4 (S4) for most users.
If procedure fails, turn off and restart from beginning.
Errors shown as 'E' numbers with audio signal.
Errors shown by LED flashes (e.g., two flashes = Error 2).
Check water supply, hose, drain pipe height, siphon/filter.
Check drain pipe, filter, siphon for blockages.
Check drain pipe, filter, siphon for blockages.
Water heating element issue or filter plate clogged; clean filter plate.
Turn off/on, restart program. Contact service if error persists.
Check indicator lights, turn off, check water/drain/filters, reset program.
Do not move/tilt during operation; ensure cycle is complete if moving.
Check plug, power button, door, and electricity supply.
Check water tap, hose bends, supply hose filter, and main connection.
Check drain pipe bends, extension connection, and filter cleanliness.
Check drain pipe connection and position (lift to at least 40cm).
Check detergent amount, items blocking arms, filter cleanliness.
Check water tap, indicator lights flashing quickly.
Check loading, food residue, spray arm blockage, program, detergent.
Check dispenser obstruction, salt container cap closure.
Check water hardness, salt/rinse aid levels; contact service if fault persists.
Check dishes knocking against each other or rotating arms.
Check inadequate airflow, rinse aid missing.
Manually remove dirt deposits after drying; contact service for continued malfunctions.
Product guaranteed under law and warranty certificate. Keep certificate and proof of purchase.
Fill online form or contact number indicated on website for assistance.
Manufacturer not responsible for printing errors or product changes.
Appliance marked according to EU directive on Waste Electrical and Electronic Equipment (WEEE).
WEEE contains pollutants and reusable components; requires specific treatment.
WEEE not household waste; hand over to relevant collection points.
Retailer must collect old appliances free of charge on a one-to-one basis.
Appliance intended for household, kitchen areas, farm houses, hotels, etc.
Excludes commercial use by expert or trained users.
Appliance for users aged 8+ with limited physical/sensory/mental capabilities.
Not for persons with reduced capabilities or lack of experience unless supervised.
Children must be supervised to ensure they do not play with the appliance.
Children aged 3 and under must be continuously supervised.
Damaged power cord must be replaced by manufacturer or service agent.
Only use supplied hose-sets for water connection; do not reuse old ones.
Water pressure must be between 0.08 MPa and 0.8 MPa.
Ensure carpets do not obstruct base or ventilation openings.
Position appliance after installation so plug is accessible.
Avoid leaving door open horizontally to prevent tripping hazards.
Refer to manufacturer's website for product info and technical data.
Refer to data plate for maximum number of place settings.
Ensure electrical system is earthed, socket compatible, and cables are not crushed.
Avoid using adaptors, multiple plugs, or extension cables.
Appliance must not be supplied via external switching device like a timer.
Unplug appliance and turn off water supply before cleaning/maintenance.
Do not pull power cord or appliance to unplug.
Water may reach very high temperatures during the wash cycle.
Do not expose appliance to rain, sun, etc.
Leaning on open door can cause appliance to tip over.
Do not lift by door; use two people for transport.
Designed for normal kitchen utensils; avoid petrol, paint, chemicals.
No need to add salt if home has water softening device.
Switch off, turn off water, do not tamper. Repair by authorized agent.
To move, lift by top, not bottom of door.
CE marking confirms compliance with EU safety, health, and environmental requirements.
Remove all packaging elements before installation.
Keep packaging materials away from children.
Do not install or use if appliance is damaged.
Follow instructions supplied with the product.
Load sharp utensils with points down or horizontally.
Appliance must be connected using new hose-sets; old ones should not be reused.
Inlet and drain hoses can be directed to left or right.
Dishwasher can connect to cold or hot water up to 60°C.
Flush new or long-unused pipes before connecting to prevent filter clogging.
Water pressure must be between 0.08 MPa and 0.8 MPa.
Connect inlet hose to a tap for water supply shut-off when not in use.
Dishwasher is fitted with a 3/4" threaded connector.
Connect inlet hose 'A' to tap 'B' with 3/4" attachment, ensuring tightness.
Inlet pipe can be extended up to 2.5m using an extension pipe from After Sales Service.
Device blocks water flow/drains excess if levels exceed normal due to malfunctions.
Prevents flooding via sensor activating valve under tap to block water.
If box 'A' (electrical parts) is damaged, unplug immediately.
Connect hose with box 'A' to tap as shown for safety system operation.
Do not cut water supply hose; replace with a longer one if needed.
Stops water flow if tube deteriorates; red mark appears in window 'A'.
Press lock device 'B' to unscrew; replace tube if red mark appears.
Sheath 'B' contains leaks from internal tube 'A' to complete cycle.
Contact Customer Service to replace supply tube after leak detection.
Outlet hose should discharge into a standpipe without kinks.
Standpipe must be min. 40cm above floor, with min. 4cm internal diameter.
Fitting an anti-odour air trap is advisable.
Outlet hose can extend up to 2.5m, max height 85cm. Extension pipe available.
Hose can hook over sink side but must not be immersed in water.
Hose clamp attached to wall highest possible position under worktop.
Check that there are no kinks in the inlet and outlet hoses.
Appearance of white stains on dishes indicates salt container needs filling.
Container for salt is located on the bottom of the machine for softener regeneration.
Use only salt specifically designed for dishwashers to avoid softener damage.
Unscrew cap, refill container, clean residue from threads, retighten.
Some water may overflow; continue adding salt until full.
After loading salt, run a complete wash cycle or a specific rinse program.
Salt dispenser capacity is 1.5 to 1.8 kg and should be refilled periodically.
For first startup, add water to overflow after filling salt container.
If 29-32.5 cm plates used, load onto lower basket after upper is raised.
Turn blocks outwards, remove/remount basket in upper position, replace blocks.
Dishes >20cm or mobile supports cannot be used in upper position.
Dishes >14cm cannot be loaded onto upper basket in models with a third basket.
Remove basket, lift on both sides, and release slowly into position.
Hold basket on both sides, lift gently, then slowly release into position.
Never lift or lower the basket from one side only.
Adjust basket before loading dishes for best results.
Adjustable racks for cups, knives, ladles, and stemmed glasses.
Load saucepans, oven dishes, plates, and bowls into the lower basket.
Load large plates (approx. 26+ cm) slightly tilted towards the rear.
Block plastic bowls on upper basket to prevent overturning from water jets.
Upper basket holds up to 24 plates or 30 glasses.
Foldable racks optimize dish stability and accommodate various sizes.
Example of a standard daily load configuration for the dishwasher.
Load dishes sensibly to ensure the best wash results.
Lower basket has safety stop for safe extraction, useful for maintenance.
Cutlery basket top can be removed for various loading options.
Position cutlery basket correctly by lowering front foldable racks for stability.
Load sharp utensils with points down or horizontally.
Use third basket for cutlery, loading knives with blade down.
Ask for comparison testing and noise level info via email.
Specify model name and number when requesting test information.
Slide or remove side shelves for extra space in upper basket for bulky items.
Use detergent specifically designed for dishwashers (powder, liquid, gel, tablet).
Hand-washing detergents lack proper ingredients and can stop the dishwasher.
Container is inside the door; press button (A) to open.
Close lid by pushing (1) then pressing until it clicks.
Use 20-30g in compartment (B); too little doesn't clean, too much is wasteful.
Ensure lower basket items do not obstruct the detergent dispenser.
Tablets may not dissolve fully in short programs; choose longer ones.
Tablets MUST be placed in the wash section of the detergent container, NOT directly in the tub.
Concentrated detergents with enzymes offer environmental benefits and protect dishes at 50°C.
Place combined detergents in container; empty rinse aid container if using.
Follow manufacturer's instructions; effectiveness depends on water hardness.
Can cause limescale deposits or reduced washing/drying performance.
Problems from combined detergent use are not covered by warranty.
Rinse aid/salt indicator lights are superfluous with TABS; ignore them.
Recommend returning to separate products if washing/drying problems occur.
Refill salt/rinse aid and run load-free cycle after returning to separate products.
Rinse aid helps dishes dry quickly and prevents spots/stains.
Container is to the left of the detergent container (Fig. A "3").
Push reference mark and pull opening tab to open lid.
Check rinse aid level through indicator eye (C) on the dispenser.
Regulator (D) is under lid; recommended position is 4.
Decrease setting for streaks, increase for spots.
System includes central container, micro filter, and flat gauze.
Filters should be checked and cleaned after each wash for best results.
Turn handle anticlockwise to remove filter unit.
Central container is removable for ease of cleaning.
Wash filter under water jet; use small brush if necessary.
Micro filter needs checking every two weeks; check other filters after each wash.
Ensure correct reassembly; poor seating affects efficiency.
Never use the dishwasher without the filters.
Remove food debris, avoid pre-rinsing, soak encrusted dishes, load properly.
Rinse silver immediately, avoid detergent, keep separate from other metals.
Use recommended maximum load size for energy, water, detergent savings.
Use ECONOMY program for light soil; longer programs are generally more efficient.
Avoid thermoplastic, wooden/plastic handles, aluminum, leaded glass.
Test wash one item first to check if decorations fade.
Avoid silver cutlery with non-stainless steel handles due to potential reaction.
Ensure new crockery or cutlery is suitable for dishwasher use.
Leave door ajar after washing for air circulation to improve drying.
Disconnect machine, clean outside with water-soaked cloth; avoid solvents/abrasives.
Tank is self-cleaning; regularly wipe door gasket to remove residue.
Run wash cycle with specialist cleaners to remove deposits; dishwasher must be empty.
Check spray heads on rotor arms are clear if dishes are not washed/rinsed properly.
Remove rotor arms by turning/pushing/unscrewing or pulling; wash under water jet.
Do not use tools that can deform spray heads.
Refit rotor arms in the same position, aligning arrow and screwing into place.
Spots from high iron salts removable with mild abrasive agent.
Turn off water supply and machine by pressing On/Off button after cycle.
Identifies buttons: ON/OFF, REMOTE CONTROL, HALF LOAD, PROGRAMME SELECTION, DELAY START, TABS, SMART DOOR, START/RESET, DISPLAY.
Provides dimensions for free-standing and built-in installation types.
Lists place settings and capacity with pans/dishes for different models.
Details water pressure, fuse, power input, and supply voltage.
Explains information provided on the appliance display during operation.
Details indicators for Temperature, Programme, Time Remaining, Salt, Wi-Fi, etc.
Explains indicator lights for ZOOM, TABS, SMART DOOR, and ADDISH functions.
Touching display during initial seconds can interrupt calibration; unplug and repeat.
Press ON/OFF button for at least 3 seconds to turn appliance on/off.
Connect to power, load dishes, close door, press ON/OFF for 3 seconds.
Select preferred language using SMART DOOR or TABS buttons.
Press START/RESET to accept language selection; WELCOME message appears.
ECO program message appears when SMART DOOR option is activated.
Appliance switches off automatically after 5 minutes if no program is selected.
Adjust parameters: LANGUAGE, SOFTENER, BUZZER, MEMO FUNCTION via Settings menu.
Turn off appliance, then hold ON/OFF and PROGRAMME SELECTION for 5s.
Use SMART DOOR/TABS buttons to adjust selected parameters.
Changing language resets all settings to default factory settings.
Open door, load dishes, select program, enable options, press START/RESET.
Duration shown left of square, temperature right; icons indicate options.
Program starts automatically after door shut and audible signal.
AUTO WASH uses sensor to adapt temperature/time to dish dirtiness for optimisation.
Dirt sensor analyzes water murkiness to adapt cycle parameters for excellent results.
Use impulse washing technology for reduced consumption, noise, and improved performance.
Intermittent pump working is a characteristic of impulse washing, not a malfunction.
Add dishes when ADDISH light is on; appliance stops, time flashes. Close door.
Cycle resumes from where it left off. Do not add dishes after indicator light off.
Opening door during drying cycle produces audio signal; drying cycle not yet finished.
Hold RESET for 3s; program cancels, new one can be set.
Check dispenser for detergent before starting a new program; top up if necessary.
Memory stores selected program; cycle resumes when power is restored.
A 5-second buzzer signals program end (if not muted).
Door opens automatically during drying; wait for end-of-cycle signal.
Extra washing arms activate in specific programs for increased washing force.
Option buttons allow customisation; indicator lights show status.
If an option is incompatible, its indicator light flashes then goes off.
Opens door slightly during/end of drying for natural drying and energy saving.
Do not force shut; ensure free space and wait for opening device.
Enabled in ECO; not available in RAPID 24, ZOOM 39, PREWASH.
Use for few dishes to save water, energy, time; use less detergent.
Optimises combined detergents (3-in-1 etc.); modifies program for best performance.
Recommended for RAPID 24'; extends duration for better tablet performance.
Light indicates salt container needs filling.
Light indicates rinse aid is running out and needs topping up.
Set delayed start time from 00:30 to 23:30 hours.
Press DELAY START, then again to increase delay by 30 mins. Press START/RESET to start.
Hold START/RESET for 3s; program cancels, previous program shown.
Procedure to mute audio signal: hold PROGRAMME SELECTION, switch on, select BUZZER, set to No.
Procedure to set MEMO FUNCTION: hold PROGRAMME SELECTION + ON/OFF, select MEMO FUNCTION.
Procedure: ON/OFF, then PROGRAMME SELECTION + DELAY START for 5s.
If no button pressed, program starts simulating a wash cycle.
Procedure: ON/OFF, then PROGRAMME SELECTION + DELAY START for 5s.
If wash cycle doesn't start, demo mode may not be disabled.
Press TABS + SMART DOOR for 3s to lock keys and prevent accidental changes.
Press TABS + SMART DOOR again, or switch off appliance, to cancel lock.
Memory saves settings during power outage; cycle resumes from where it left off.
Appliance can be remote controlled via a simple app.
Download app, create profile, enroll appliance following app instructions.
App available for Android and iOS tablets and smartphones.
Explore app menus in DEMO mode for Wi-Fi features.
Ensure router is on, smartphone connected to Wi-Fi, and Bluetooth enabled.
Turn on dishwasher by pressing ON/OFF for 3 seconds when instructed by app.
Press PROGRAMME SELECTION/ENROLMENT Wi-Fi for 3s; enrollment status changes.
Enter Wi-Fi password in app and complete procedure; 'CONNECTED' message appears.
'CONNECTED' and 'REMOTE CONTROL' messages appear; Wi-Fi light is steady.
If enrollment fails, 'TRY AGAIN' appears; repeat procedure.
Refer to guide or link for more information on enrollment.
Repeat enrollment, remove product from APP, for problems or router changes.
Fill dishwasher, add detergent, close door, turn on, press PROGRAMME SELECTION/ENROLMENT Wi-Fi for 3s.
Press PROGRAMME SELECTION/ENROLMENT Wi-Fi to exit.
Wi-Fi light flashes slowly, 'REMOTE CONTROL OFF' appears; last program shown.
Wi-Fi light flashes slowly, 'REMOTE CONTROL OFF' appears; remaining time shown.
Hold START/RESET for 3s; cycle cancels, Wi-Fi light flashes slowly.
Press ON/OFF for 3s; cycle pauses, Wi-Fi light flashes slowly.
Opening door disables REMOTE CONTROL; close door to resume.
Explains Wi-Fi light statuses: FIXED ON, SLOW FLASHING, QUICK FLASHING, etc.
Most efficient for energy/water for normally soiled tableware.
For heavily soiled pans and items left all day.
For normal soiled pans and items left all day.
Single cycle for delicate dishes like glassware; quick wash for after meal.
Quick wash for dishes to be washed immediately after meal; load of 6 persons.
Short cold pre-wash for items stored until ready for full load.
Antibacterial cycle for sterilising dishes, babies' bottles etc.
Intended for rapid washing of very dirty dishes.
For everyday dishwashing; two final rinses ensure hygiene.
Fast cycle for normal dishes, optimized by sensor.
Quiet washing cycle, ideal for night use and reduced energy fares.
Suitable for delicate crockery and glassware, less soiled items.
For programs with prewash, add a second dose of detergent directly.
Hardness causes stains; softener unit supplies softened water using salt.
Procedure to set softener based on water hardness (French/German grading).
Turn on, hold PROG SELECTION+ON/OFF, select SOFTENER S4, adjust, switch off.
Softener unit is factory set at level 4 (S4) for most users.
If procedure fails, turn off and restart from beginning.
Errors shown as 'E' numbers with audio signal.
Errors shown by LED flashes (e.g., two flashes = Error 2).
Check water supply, hose, drain pipe height, siphon/filter.
Check drain pipe, filter, siphon for blockages.
Check drain pipe, filter, siphon for blockages.
Water heating element issue or filter plate clogged; clean filter plate.
Turn off/on, restart program. Contact service if error persists.
Check indicator lights, turn off, check water/drain/filters, reset program.
Do not move/tilt during operation; ensure cycle is complete if moving.
Check plug, power button, door, and electricity supply.
Check water tap, hose bends, supply hose filter, and main connection.
Check drain pipe bends, extension connection, and filter cleanliness.
Check drain pipe connection and position (lift to at least 40cm).
Check detergent amount, items blocking arms, filter cleanliness.
Check water tap, indicator lights flashing quickly.
Check loading, food residue, spray arm blockage, program, detergent.
Check dispenser obstruction, salt container cap closure.
Check water hardness, salt/rinse aid levels; contact service if fault persists.
Check dishes knocking against each other or rotating arms.
Check inadequate airflow, rinse aid missing.
Manually remove dirt deposits after drying; contact service for continued malfunctions.
Product guaranteed under law and warranty certificate. Keep certificate and proof of purchase.
Fill online form or contact number indicated on website for assistance.
Manufacturer not responsible for printing errors or product changes.
Appliance marked according to EU directive on Waste Electrical and Electronic Equipment (WEEE).
WEEE contains pollutants and reusable components; requires specific treatment.
WEEE not household waste; hand over to relevant collection points.
Retailer must collect old appliances free of charge on a one-to-one basis.
General| Type | Freestanding |
|---|---|
| Size | Full-size |
| Number of Place Settings | 16 place settings |
| Energy Efficiency Class | C |
| Noise Level | 43 dB |
| Wash Programs | 9 |
| Height | 85 cm |
| Width | 60 cm |
| Depth | 60 cm |
| Noise emission class | B |
| Number of washing programs | 9 |
| Adjustable upper basket | Yes |
| Cutlery drawer | Yes |
| Wi-Fi | Yes |
| Drying Efficiency Class | A |
| Delay Start | Yes |
| Half Load Option | Yes |
| Dimensions (H x W x D) | 85 x 60 x 60 cm |
| Product type | Freestanding |
To Next Page
