8

Position the template onto the
reverse of the furniture door. It
is possible
to mount the hinges
and closure magnet on the right
or left-hand sid
e depending on
your requirements. Mark the
screw hole positions, then drill
out these positions.

Fix the hinges in place
with the
4 screws provided (A).

Fix the magnet (B)
in place
using screw (C).

Mount the plate (D)
on the right
or left-
hand side, depending on
your installation requirements
.
Place the plastic support
(E)
under the plate and fix it
in
position with screw (F).

Snap mount cap (G)
in the
lower position.
Instructions for mounting the
furniture door
