Mount the furniture door to the
front of the was
hinges. Fix the spacers (I)
place with the 2 screws (J)
then fix the hinges with 2
(H).
Slide the washer
opening of
the size indicated in
the diagram opposite. A furniture
plinth may be run across th
e front
of the appliance, but its height will
be dictated by the height the
washer is set at.
The 4 adjustable feet allow the
height of the washer to be
adjusted from 820 mm to a
maximum of 840 mm. To adjust
the height, you should remove
the nuts fitted to each foot and
replace these with the 5 mm
nuts supplied. Raise the feet to
your desired height and then
fully tighten the lock nut to the
base of the washer.
We suggest mounting the
furniture door so that it opens
towards the left, which is the
same direction as the porthole
door. This
will leave more
space when you are loading
washing into the appliance.
