10
To operate: pull up the front panel, turn on the cooker hood, and then choose the fan
speed setting.
To turn the unit off, there are two options:
1. Turn off the fan with the slide switch.
2. Push down the front panel (with the fan still switched on). This will turn the hood
off, and when the cooker hood is next opened, the fan speed will be the same
as the last time it was operate.
3. Whether the front panel is open or not, or the fan in use or not, the light can be
operated independently.
How to use the control panel: (Diagram above)
There are 3 speeds for the motor and on off switch for the lamp.
Slide the switches for operation.
Motor Operation
0- off
1- Low Power Setting
2- Mid Power Setting
3- High Power Setting
Light Operation
0- Off
1- On
TROUBLESHOOTING
Fault PossibleCause Solution
Light on, but motor
does not work
Fan switch turned off Select a fan switch position.
Fan switch failed Contact service center.
Motor failed Contact service center.
Light does not
work, motor does
not work
House fuses blown Reset/Replace fuses.
Mains power cable is loose or
disconnected
Refit mains power cable to
power outlet.
Switch power outlet on.
Oil leakage
One way valve and the outlet
are not tightly sealed
Take down the one way valve
and seal with sealant.
Leakage from the connection of
chimney and cover
Take chimney down and seal.
Lights not working Broken or faulty bulbs
Replace blubs as per this
instruction.
Insufficient suction
The distance between the
cooker hood and the gas top is
too far
Refit the cooker hood to the
correct distance.
