Candy CBP613NGR/S User Manual

5
INSTALLATION(VENTOUTSIDE)
If you have an outlet to the outside, your cooker hood can be connected as below
picture by means of an extraction duct (enamel, aluminum, flexible pipe or non-
flammable material with an interior diameter of 120mm)
1. Before installation, turn the unit off and unplug it from the outlet.
2. The cooker hood should be placed at a height of 65-75cm above the cooking
surface for best efficiency.
3. Install the cooker hood between two cupboards. Drill and screw on the side boards
of the cupboards (the holes ≤ 2mm).The distance between the head of the screw
and the side board should be 5mm, and the distance between the screw and the
cooking surface should no less than 1040mm. If there is not room enough, you can
place it higher or lower.
65cm
75cm

Candy CBP613NGR/S Specifications

General

Brand	Candy
Model	CBP613NGR/S
Category	Ventilation Hood
Language	English
