35
DESCRIPTION OF THE CONTROL PANEL
A "ON/OFF" button
B "PROGRAMME SELECTION" button
C "DELAY START" button
D
"START"/"RESET" button
(start/cancelling programme)
E
"EXPRESS"
button
F "PROGRAMME SELECTION" lights
G "SALT EMPTY" light
H "PROGRAMME STATUS" lights/
"DELAY START" time lights
I
"EXPRESS"
light
L Programme guide
DIMENSIONS
TECHNICAL DATA
CONSUMPTION (main programmes)*
Programme Energy (kWh) Water (L)
INTENSIVE
UNIVERSAL
ECO
RAPID 29'
2,10
1,55
1,06
0,73
21
15
12
9
Width x Height x Depth (cm) 60 x 85 x 60
Depth with door open (cm) 120
EN 50242 place load
Capacity with pans and dishes
Water supply pressure (MPa)
Fuse / Power input / Supply voltage
15
9 persons
Min. 0,08 - Max. 0,8
See rating plate
Power consumption of the off-mode and of the left-on mode: 0,10 W / 0,60 W
*Values are measured in a laboratory according to European Standard EN 50242 (consumption may
vary according to conditions of usage).
59,8 x 82 x 57,3
117
With working top Without working top
