Candy CDPH 2L1049W - Plumbing and drainage options

3
9
1
2
Plumbing and drainage options. Determine which is
more suitable
If space is limited
for fixing, push
hose through drain
hose support
to required height
min. radius
200 mm
min. 750 mm
step 4
Dishwasher and Ø 38 mm Standpipe
750-882.5 mm
min.
120mm
38mm
Installation instructions
