8
SPECIFICATIONS
Power Consumption
230-240V/50Hz,
1200W(Microwave); 900W(Grill)
Output 700W
Operation Frequency 2450MHz
Outside Dimensions 262mm(H)×452mm(W357mm(D)
Oven Cavity Dimensions 198mm(H)×315mm(W297mm(D)
Oven Capacity Compact 20Litres
Net Weight Approx.11kg
PRODUCT DIAGRAM
1. Door Safety Lock System
2. Oven Window
3. Shaft
4. Roller Ring
5. Control Panel
6. Wave Guide
(Please do not remove the mica
plate covering the wave guide)
7. Glass Tray
8. Grill Heater
9. Metal Rack
