INSTRUCTIONS FOR INSTALLATION OF THE UNIT
All tasks involved in installing the applianc
e must be carried out by skilled personnel.
Any work is to be performed with the appliance unplugged.
Electrical connection:
make sure that the voltage corresponds to that indicated on the tag on the side.
The oven must be connected using a cable with a
minimum cross
-
section of 1.5 mm
on the rear, and with an omni-
polar switch compliant with current standards with a
distance of aperture between contacts of at least 3 mm.
Attention: earth connection is required by law.
The manufacturer will in no way be
held liable if accident prevention standards area
not observed.
Insertion into the furniture unit:
The appliance can be inserted either under a worktop or into a column. In either case
comply with the dimensions shown in figures 1 and 2.
For column instal
lation, in order to ensure proper ventilation, it is indispensable to
provide an opening of at least 85
-
90mm as shown in figure 1.
The oven is secured to the furniture unit by four screws A located in the holes of
the perimeter frame (see fig. 1).
Do n
ot
use the door a lever when installing the oven.
Do not place excessive pressure on the oven door when it is open.
26
