SET-UP STEP 2STEP 1 STEP 3 STEP 4 PRE-RIDE CHECK
Loosen the seatpost clamp with the Allen key. On the seatpost, locate
the minimum insertion line.
Insert the seatpost into the frame beyond the minimum insertion
line, then hand tighten the clamp using the Allen key, enough so the
seatpost can’t be pulled from the frame.
Remove the fork protector packaging.
Carefully lift the bike from the box and gently place the fork ends on
the ground.
A.
B.
C.
D.
A
B
C
D
