SET-UP STEP 2STEP 1 STEP 3 STEP 4 PRE-RIDE CHECK
Locate the skewer and remove it from the packaging. The skewer is
comprised of ve major parts: the skewer itself; a washer; two conical
springs; and the adjusting nut.
Unthread and remove the adjusting nut and the neighboring conical
spring from the skewer.
Insert the skewer into the wheel axle on the opposite side of the disc
brake rotor. Push the skewer through the hub to the other side of the
wheel.
Place the conical spring back onto the skewer with the narrow end
pointing toward the wheel, then thread on the adjusting nut.
A.
C.
D.
A
B
C
D
