Cannondale TRIGGER - Rear Derailleur Hanger - CK32570000 S; Hanger Replacement

13
134910 Rev 1.
1.
2.
3.
2.
Loctite 232
5 Nm
M3X12
ENGLISHTRIGGER/JEKYLL - OWNERS MANUAL SUPPLEMENT
Hanger Replacement
Hanger replacement kit is available as Cannondale kit
- CK3257U00OS.
The kit includes the hanger (1) and a new pivot bolt
(3). Before installing a new hanger, be sure to clean
any dirt or debris on the dropout with a nylon brush
(old toothbrush). Inspect the area for any damage.
Lightly grease the dropout surface. Apply Loctite 242
(blue) to the pivot bolt (4). Align the hanger on the
opposite side of the dropout and tighten the bolt to
the specied torque.
Rear Derailleur Hanger - CK3257U00OS
