7. Settings
-102-
7.9 Screen
The Screen screen is displayed when the Screen icon is clicked.
Click the tabs, and set the parameters.
To save the settings and exit the Screen screen, click [OK].
Screen screen
7.9.1 Main Image Info. tab
On this tab, the image information to be displayed on the main image is set when the main & thumbnail
images are displayed (see page 44) on the screen.
Check the items to be displayed.
Main Image Info. tab
Displayed Items Display Description
Retinal Camera Mode Color is displayed.
Image No.
This item is indicated as the No. Image No. The images are displayed
in the sequence in which they were taken.
X2 If the image is taken at x2, the magnification rate (x2) is displayed.
R/L Either R (right eye) or L (left eye) is displayed.
Content Time The photography time is indicated in hours:minutes:seconds.
Patient ID This item is indicated as the ID: Patient ID.
To Next Page
