Introduction

17
Ad Zoom lever ( 40)
Af PHOTO button ( 73)
Ag POWER button
Ah Joystick ( 27)
Aj LCD screen ( 23)
Ak FUNC. button ( 28, 90)
Al / (play/pause) button ( 43)/
START/STOP button ( 38)
Sq (stop) button ( 43)/
PLAYLIST button ( 46)
Sa VIDEO SNAP (video snapshot) button
( 55)
Ss (camera/play) button ( 26)
Sd ON/OFF (CHG) (charge) indicator:
Green – On
Orange – Standby ( 41)
Red – Charging ( 19)
Sf Start/Stop button ( 38)
LCD panel
Top view
Back view
