Canon imagePROGRAF iPF760 Setup Guide

11
Connect the printer to a computer
15
Click Quit.
This completes printer driver installation.
Next, connect the printer to the computer.
17
Click Next.
18
Select the printer to setup and
click Next.
MEM
O
• To register the printer by entering its IP
address, click Registering IP Address.
Enter the IP address of the desired
printer in IP Address and click Next.
19
After entering your preferred name for
the printer in Printer Name and the
installation location in Location, click
Register.
Make sure that the printer is on, and then connect the printer to the computer or the network
with a cable. When connecting to a network, pass the network cable through the wiring bracket
(a).
• For USB connections
• For network connections
a
MEM
O
• Be careful not to insert the USB cable into the Ethernet port.
1616
Select the printer to setup
20
Click Finish.
MEM
O
• To register another printer, click
Continue Registration, and repeat
steps 17 to 19.
21
Click OK.
MEM
O
• If the same model of printer is already
registered on the computer, a screen is
displayed for printer selection. Select
the desired printer and click Next.
22
The following screen is displayed and
paper information is updated. When the
paper information has been updated, the
screen is no longer displayed.
23
Next, install the User Manual.
Insert the provided User Manuals
CD-ROM in the CD-ROM drive.
24
Double-click the iPFxxxx Manual
Installer icon on the CD-ROM. (iPFxxxx
represents the printer model.)
25
Select the region where the printer will
be used and the language of the user
manual to install, and then click OK.
Install the User Manual
26
Check the message and click Continue.
27
After reading the software license
agreement, click Continue.
28
Click Agree.

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
