Canon imagePROGRAF iPF765 Basic Guide

Cause Corrective Action
The Printhead noz-
zles are clogged.
(See "Cleaning the Printhead.") →P.41
If the message is still displayed when printing, replace the Printhead.
(See "Replacing the Printhead.") →P.27
Press ▲ or ▼ to select Print, and then press the OK button to resume printing. However, note that this error may
affect the printing quality.
If OK is shown on the Display Screen, clean the Printhead.
1. Press the OK button on the Control Panel to stop printing.
2. Clean the Printhead.
(See "Cleaning the Printhead.") →P.41
If the message is still displayed when printing, replace the Printhead.
(See "Replacing the Printhead.") →P.27
iPF765 Execute printhead cleaning.
Basic Guide
Error Message Messages regarding printheads
123

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
