Canon imagePROGRAF iPF765 Basic Guide

First Level Second Level Third Level Fourth Level Fifth Level Sixth Level Seventh Level Eighth Level
Test Print Nozzle Check ┋ Status Print ┋ Interface Print ┋ GL2 Set Print ┋ Paper Details ┋ Print
Job Log ┋ Menu Map ┋ Color Palette
Adjust
Printer
Head Posi.
Adj.
Auto(Standard) ┋ Auto(Advanced) ┋ Manual (*1)
Head Inc. Adj.
Feed Priori-
ty
Adj. Priority Automatic *┋ Print Quality ┋ Print Length
Adj. Quality
(*2)
Auto(GenuinePpr) ┋ Auto(OtherPaper) ┋ Manual
Adjust
Length (*3)
Adjust-
mentPrint
A:High ┋ B:Standard/Draft
Change
Settings
A:High ┋ B:Standard/Draft
Mainte-
nance
Head
Cleaning
Head Cleaning A ┋ Head Cleaning B
Nozzle Check
Replace P.head
Repl. maint cart
Head Info ProductName: ┋ s/n: ┋ Days elapsed: ┋ Count [Mdot]:
GL2 Set-
tings
Quality
Manager
Color Mode Monochrome ┋ Color (CAD) 1 *┋ Color (CAD) 2 ┋ Color (CAD)
3 ┋ Color (CAD) 4 ┋ Color (CAD) 5
Print Quali-
ty
Fast ┋ Standard *┋ High
Input Reso-
lution
600dpi *┋ 300dpi
Print (Econ-
omy)
Off *┋ On
Paper Man-
ager
Paper
Source
Automatic *┋ Roll Paper ┋ Cut Sheet
Margin 3mm(Standard) *┋ 5mm
Conserve
Paper
Off *┋ On
Auto Rotate Off *┋ On
Nesting Use Nest-
ing
Off *┋ On
Nesting
WaitTime
(*4)
xx min.
Cut Lines
(*4)
Off *┋ On
Line & Pen
Manager
Enable
merge
Off *┋ On
Pen Setup Select Pa-
lette
Software *┋ Palette A ┋ Palette B ┋ Factory
Define Pa-
lette
Palette A (Select the
pen number)
Width (Indicates
the value of
Width)
Color 0～255
Line Attrib-
utes
No Setting
┋ Circle
Setting
Menu Structure iPF765
Basic Guide
Printer Parts Operations and Display Screen
50

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
