Canon imagePROGRAF iPF9400 Brochure & Specs

7
* The maximum printable length varies depending on the
application, OS, and RIP used. The maximum printable
length from Canon Printer Driver is 50 feet.
** For Adobe Photoshop 6, 7, CS, CS2, CS3, CS4 running
on Windows 2000/XP/Windows Vista (32 bit)/Windows 7
or Macintosh OS X 10.2/10.3/10.4/10.5/10.6.
*** For Digital Photo Professional version 2.1 or later running
on Windows 2000/XP/Windows Vista (32 bit)/Windows 7
or Macintosh OS X 10.2/10.3/10.4/10.5/10.6.
n
For imagePROGRAF Printer Driver. For printing from
PostScript
®
applications such as Adobe Illustrator
®
or
QuarkXPress
®
, please use a PostScript compatible RIP
package. For a list of Canon recommended RIP packages,
please consult with Canon Alliance and Industry Market
program list of RIP vendors.
Print-Heads
P
F-05 (2)
Technology
FINE (Full-photolithography Ink-jet Nozzle Engineering)
Print Resolution (Max.)
Up to 2400 x 1200 dpi
Ink T
ype
LUCIA EX Ink (Pigment-based)
Ink Tank
PFI-106 (130ml): BK, MBK, C, M, Y
, PC,
PM, GY, PGY, R, G, B
PFI-206 (300ml): BK, MBK, C, M, Y
, PC,
PM, GY, PGY, R, G, B
Colors
Cyan, Photo Cyan, Magenta, Photo Magenta,
Yellow, Black, Matte Black, Gray, Photo Gray, Red,
Green, Blue
Ink T
ank Shipped with Printer
12 Colors (90ml Starter Tank Each Color)
Hard Disk Capacity
iPF6450: 250GB
iPF6400: N/A
Printer Memory
384MB
Media Feed
Top-loading Roll Feed
One Roll, Front Output
T
op-loading Manual Feed
One Sheet, Front Output
Front-loading Manual Feed
One Sheet, Front Output
Media Width
8" – 24" (Cut Sheet and Roll)
Minimum Media Length
Top-loading Roll Feed
8" (203mm)
Top-loading Manual Feed
11.0" (279mm)
Front-loading Manual Feed
13.8" (350mm)
Maximum Print Length
Manual Feed
63" (1.6m)
Roll Feed
59' (18m)*
Front-Loading Manual Feed
36" (914mm)
Borderless Printing Widths (Roll Media Only)
10"/14"/16"/17"/24"/B4 [9.84"(250mm)]/
A2 [16.54"(420mm)]/ B2 [20.28"(515mm)]/
A1 [23.38"(594mm)]
Printer Stand
Standard
Media Thickness
T
op-loading Manual Feed
0.07mm - 0.8mm (2.8mil - 31.4mil)
Front-loading Manual Feed
0.5mm - 1.5mm (19.6mil - 59.0mil)
Top-loading Roll Feed
0.07mm - 0.8mm (2.8mil - 31.4mil)
Media Core Sizes
2" or 3" Core (with Supplied Adapter)
Printable Margins
Manual Feed (T
op/Front)
Leading and Left/Right Edges: 0.12" (3mm)
Trailing Edge, Front Feed: 0.90" (23mm)
T
railing Edge, Top Feed: 0.12" (3mm) Except
Art Paper 0.90" (23mm)
Roll Feed, All Sides: 0.12" (3mm) or 0" for Borderless
Maximum Media Roll Outer Diameter
5.9“ (150mm)
Bundled Software
Printing Software
Canon Printer Driver, Print Plug-in for Photoshop,**
Print Plug-in for DPP,*** Printer Driver Extra Kit
(Free Layout, imageRUNNER Linking Function),
Print Plug-in for Microsoft Office
Applications
PosterArtist Lite
Utilities
imagePROGRAF Status Monitor (Windows),
Print Monitor (Macintosh), Media Configuration
Tool, Remote UI, Accounting Manager, Color
Calibration Management Console
Printer Language
GARO (Canon Proprietary)
Operating System
n
Windows XP (32/64-bit), Server 2003 (32/64-bit),
Server 2008 (32/64-bit), Windows Vista
®
(32/64-bit),
Windows 7 (32/64-bit); Macintosh
®
OS X
10.5.8 - 10.7x
Interface
Standard
USB 2.0 High-Speed
10/100/1000Base-T/TX
Acoustic Noise
Operation 47dB or Less
Power Supply
AC 100-240V (50-60Hz)
Power Consumption
Maximum
100W or Less
Standby (100-120V)
6W or Less
Power Off
.5W or Less (compliant with executive order)
Certifications
UL, FCC Class B, ENERGY STAR
®
Operational Environment
Temperature
59 – 86 F° (15 – 30 C°)
Relative Humidity
10 – 80% (No Condensation)
Dimensions
iPF6450/iPF6400 Printer and Stand (H x W x D)
39.4" x 48.3" x 27.6"
iPF6450 Printer with optional SU-21 Spectrophotometer installed
(H x W x D)
39.4” x 48.3” x 34.3”
W
eight
iPF6450/iPF6400 Printer
Approx. 154 lb.
iPF6450 Printer with optional SU-21 Spectrophotometer installed
Approx. 200 lb.
User
-Replaceable Items
Print-Head (PF-05)
Maintenance Cartridge (MC-16)
Options
Roll Holder Set RH2-25
PosterArtist (PC Only)
Optional SU-21 Spectrophotometer for iPF6450
Model
X-Rite SU-21
Color Measurement Width
480mm
Max. Media Thickness
0.50mm
XRGA Compliant
Yes
ISO 13655 Compliant
Yes
User Switchable UV Filter
Yes
White/Black Backing
Included on One Strip
Support for Third-party RIPS
Most Leading Third-party RIPs
imagePROGRAF
SPECIFICATIONS

Canon imagePROGRAF iPF9400 Specifications

General

Color	Yes
Printing colors	Black, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Bundled software	Canon Printer Driver, Print Plug-in for Adobe Photoshop. Print Plug-in for Digital Photo Professional, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft® Word/Excel/PowerPoint (PC only), Accounting Manager, Gallery Wrap Feature
Media thickness	0.07 – 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (rolls)	254 - 1524 mm
Media width (sheets)	203.2 - 1524 mm
Maximum roll diameter	150 mm
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	68 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Power consumption (off)	5 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	766 mm
Width	2299 mm
Height	1144 mm
