Confirming the Installation Space
When installing the printer, it is recommended that you secure the following space around the printer.
Important
The space required in front of the printer varies depending on how the basket is used.
When using the BU-06 desktop basket
Required space* (W x D x H)
1,168 mm × 1,425 mm × 1,465 mm
Required space** (W x D x H)
1,168 mm × 1,125 mm × 745 mm
** 500 mm
100 mm
500 mm*
100 mm
100 mm
500 mm
* When using the BU-06 desktop basket
** When not using the desktop basket
When using the SD-24 printer stand
Required space* (W x D x H)
1,168 mm × 1,470 mm × 1,374 mm
Required space** (W x D x H)
1,168 mm × 1,125 mm × 745 mm
** 500 mm
100 mm
500 mm*
100 mm
100 mm
500 mm
* When using the SD-24 printer stand
** When not using the printer stand
ENGLISH

Canon imagePROGRAF TC-20 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	-
Page description languages	SGRaster
USB connector	USB Type-A / USB Type-B
Ethernet LAN data rates	100 Mbit/s
Product color	Black, White
Sound power level (standby)	35 dB
Sound pressure level (printing)	42.5 dB
Media thickness	0.08 - 0.28 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll diameter	110 mm
Paper tray media types	Coated paper, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A3, A4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (sleep)	2.4 W
Power consumption (typical)	28 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	545 mm
Width	968 mm
Height	395 mm
