Using rolls with a 3-inch paper core
Holder Stopper (Left Side) Roll Holder (Right Side)
Align the tips (a) of the 3-Inch Paper Core Attachment L with
the holes (b) of the Holder Stopper and insert it firmly.
Align the tips (a) of 3-Inch Paper Core Attachment R with the
holes (b) of the Roll Holder and insert it firmly.
3
With the edge of the roll paper facing forward as shown,
insert the Roll Holder from the right of the roll. Insert it
firmly until the roll touches the flange (a) of the Roll Hold-
er, leaving no gap.
Attaching the Roll Holder to Rolls
iPF780
User's Guide
Handling and Use of Paper Handling rolls
372
