Canon iPF780 - Printer Parts; Front

Printer parts
Printer parts
Front .............................................................................................................................................................................................472
Side ............................................................................................................................................................................................... 474
Top Cover (Inside) .................................................................................................................................................................. 475
Roll Cover (Inside) .................................................................................................................................................................. 476
Carriage ...................................................................................................................................................................................... 476
Ink Tank Cover (Inside) ......................................................................................................................................................... 477
Stand ............................................................................................................................................................................................478
Control Panel ............................................................................................................................................................................ 434
Front
Front
a Roll Cover
Open this cover to load rolls. (See "Roll Cover (Inside).") ➔ P.476
b
Paper Feed Slot
When loading paper, insert it here.
c Roll Ledge
When loading rolls, rest the Roll Holder here before loading it in the Roll Holder Slot.
d Release Lever
When releasing the Paper Retainer, push this lever back.
e
Control Panel
Use this panel to operate the printer and check the printer status. (See "Control Panel.") ➔ P.434
Front
iPF780
User's Guide
Printer Parts Printer parts
