Chapter 6
6-10
T-6-27
26 H1_LT_B OUT Head(L) latch signal
27 GND - GND
28 H1-C-DATA-5-EV_B OUT Even head(L) data signal 5(C)
29 GND - GND
30 H1-B-HE-3_B OUT Head(L) heat enable signal 3(B)
31 GND - GND
32 H1-C-DATA-4-EV_B OUT Even head(L) data signal 4(C)
33 GND - GND
34 H1-B-DATA-3-EV_B OUT Even head(L) data signal 3(B)
35 GND - GND
36 H1-B-DATA-2-EV_B OUT Even head(L) data signal 2(B)
37 GND - GND
38 H1-A-DATA-1-EV_B OUT Even head(L) data signal 1(A)
39 GND - GND
40 H1-A-HE-1_B OUT Head(L) heat enable signal 1(A)
41 GND - GND
42 H1-A-DATA-0-EV_B OUT Even head(L) data signal 0(A)
43 GND - GND
44 H1-A-HE-0_B OUT Head(L) heat enable signal 0(A)
45 GND - GND
46 H1-A-DATA-0-OD_B OUT Odd head(L) data signal 0(A)
47 GND - GND
48 H1-A-DATA-1-OD_B OUT Odd head(L) data signal 1(A)
49 GND - GND
50 H1-B-HE-2_B OUT Head(L) heat enable signal 2(B)
J3401
Pin Number Signal name IN/OUT Function
1 VMGND - GND
2 VMGND - GND
3 VMGND - GND
4 VMGND - GND
5 VH_MONI1 IN VH controll signal 1
6 VH_ENB OUT VH power supply ON/OFF signal
7 VH_MONI2 IN VH controll signal 2
8 GND - GND
9 +3.3V OUT Power supply(+3.3V)
10 +3.3V OUT Power supply(+3.3V)
11 GND - GND
12 SNS5V OUT Power supply(+5V)
13 SNS5V OUT Power supply(+5V)
14 VM OUT Power supply(+32V)
15 VM OUT Power supply(+32V)
16 VM OUT Power supply(+32V)
17 VM OUT Power supply(+32V)
18 VM OUT Power supply(+32V)
19 VM OUT Power supply(+32V)
20 VM OUT Power supply(+32V)
21 VM OUT Power supply(+32V)
22 VMGND - GND
23 VMGND - GND
24 VMGND - GND
25 VMGND - GND
J3602
Pin Number Signal name IN/OUT Function
