CHAPTER 7 TROUBLESHOOTING
3.1.5 The output is foggy horizontally.
3.1.6 The output has fuzzy, black horizontal lines.
General conditions
1) Execute ‘PRINT test’. Is the output image normal? (See 3.21.5 of
Chapter 2.)
YES: Go through steps 4) to 8).
NO: Go through steps 2) to 3).
Transfer guide assembly
2) Clean the transfer guide assembly. Is the problem corrected?
YES: End.
Drum unit, Developing unit
3) Try replacing the drum unit. Is the fault corrected?
YES: End.
NO: Replace the developing unit.
Selfoc lens array (contact sensor)
4) Clean the selfoc lens array of the contact sensor. (See 4.3.1 of Chap-
ter 6.)
YES: End.
Contact sensor LED intensity auto adjustment
5) Execute contact sensor LED intensity auto adjustment. Is the prob-
lem corrected? (See 1.2.4.1 of Chapter 7.)
YES: End.
Connector
6) Is the connection of the following connectors normal: J501 and
J503 on the analog processor PCB; J317 on the image processor
PCB; and J504 of the contact sensor?
NO: Connect them firmly. If the flexible cable has a scratch, replace it.
Contact sensor
7) Try replacing the contact sensor. Is the problem corrected?
YES: End.
Analog processor PCB, Image processor PCB
8) Try replacing the analog processor PCB. Is the problem corrected?
YES: End.
NO: Replace the image processor PCB.
