Canon LASER SHOT LBP3500 User Manual

5-21
Routine Maintenance
5
Adjusting the Printing Position
This section describes the setting procedure for the following Printing Position
Adjustment Print printed with [Paper Source] in the [Printing Position Adjustment
Print] dialog box set to [Cassette 1], as an example.
In this case, adjust the printing position by -2.59 mm to the left.
1 Display the Printer Status Window.
For details on methods for displaying the Printer Status Window, see "Displaying
the Printer Status Window," on p. 4-86.
2 From the [Options] menu, select [Device Settings] ➞ [Printing
Position Adjustment].
The [Printing Position Adjustment] dialog box is displayed.

Canon LASER SHOT LBP3500 Specifications

General

Print Technology	Laser
Print Speed	25 ppm (A4)
Connectivity	USB 2.0
Memory	8 MB
Duplex Printing	Manual
Weight	11.2 kg
Paper Capacity	250 sheets
Media Size	A4, Letter, Legal, Executive
Print Resolution	600 x 600 dpi
