110  Video
To display the audio level indicator
Usually, the audio level indicator will be displayed only after activating
the manual adjustment of the audio recording level. You can choose to
display it also when the audio level is adjusted automatically.
NOTES
• When the audio level meter reaches the red point (0 dB), the sound may
be distorted.
• If the audio level is too high and the sound gets distorted, activate the
microphone attenuator with the p > [Microphone Attenuator] set-
ting.
• We recommend using headphones to check the sound level while
adjusting the audio recording level or when the microphone attenuator
is activated.
Using Headphones
Use headphones for playback or to check the audio level while record-
ing. The headphones are connected to the AV OUT/× terminal, which
is used for both the headphones and the audio/video output. Before
connecting the headphones, follow the procedure below to change the
function of the terminal from AV output to × (headphones) output.
Operating modes:
1Press .
2 Change the function of the terminal to headphones output.
3 Connect the headphones to the AV OUT/× terminal.
[FUNC.] > [ä Mic. Level] > [m] (automatic) >
[Audio Level Indicator] > [X]
[ Other Settings] > q > [AV/Headphones] >
[Ó Headphones] > [K]
COPY

Canon LEGRIA HF R306 Specifications

General

Sensor type	CMOS
Total megapixels	3.28 MP
Optical sensor size	1/4.85 \
Effective megapixels (image)	2.07 MP
Digital zoom	1020 x
Optical zoom	32 x
Image stabilizer	Yes
Focal length range	2.8 - 89.6 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	4.5
Minimum aperture number	1.8
Focal length (35mm film equivalent)	38.5 - 1232 mm
Maximum focal length (35mm film equiv)	1232 mm
Minimum focal length (35mm film equiv)	38.5 mm
Memory slots	1
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Internal storage capacity	0 GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.1 m
Scene modes	Beach, Fireworks, Night, Portrait, Snow, Sports, Spotlight, Sunset
Built-in flash	No
Shutter speed (video)	0.001 s
Display diagonal	3 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Self-timer delay	10 s
Minimum illumination	4 lx
Product color	Black
Capture modes	FXP, MXP, SP, XP+
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Audio system	Dolby Digital 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	1 h
Cables included	USB

Weight and Dimensions

Depth	115 mm
Width	54 mm
Height	55 mm
Weight	250 g
