Page #109 background imageLoading...
Page #109 background image
Adjusting Print Head Position
Any error in the print head installation position can cause color and line shifts. Adjusting the print head
position improves print results.
Auto head alignment
1.
Select Utilities from Remote UI
2.
Click Auto head alignment
A message appears.
3.
Load paper in printer
In the cassette, load 1 sheet of plain A4-sized or Letter-sized paper.
4.
Run head position adjustment
Check that the printer power is on, and then click Yes.
Head alignment starts. Proceed with the operations in accordance with the messages on the screen.
Important
• While the printer is printing, do not open the printer scanning unit / cover.
Note
• You can print and check the current settings by clicking on Print the head alignment value.
109
