Canon PIXMA TR7540 User Manual

Adjusting Print Head Position
Any error in the print head installation position can cause color and line shifts. Adjusting the print head
position improves print results.
Auto head alignment
1.
Select Utilities from Remote UI
2.
Click Auto head alignment
A message appears.
3.
Load paper in printer
In the cassette, load 1 sheet of plain A4-sized or Letter-sized paper.
4.
Run head position adjustment
Check that the printer power is on, and then click Yes.
Head alignment starts. Proceed with the operations in accordance with the messages on the screen.
Important
• While the printer is printing, do not open the printer scanning unit / cover.
Note
• You can print and check the current settings by clicking on Print the head alignment value.
109

Canon PIXMA TR7540 Specifications

General

Print Technology	Inkjet
Maximum Print Resolution	4800 x 1200 dpi
Scanner Type	Flatbed, ADF
Scanner Resolution (Optical)	1200 x 2400 dpi
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	10 ppm
Two Sided Printing	Yes
Multiple Copy	Up to 99 pages
Fax Type	Super G3
Fax Resolution	300 x 300 dpi
Display	Color
Interface Type	USB, Ethernet, Wi-Fi
Mobile Printing	AirPrint, Google Cloud Print, Mopria
Supported Operating Systems	Windows, Mac
Paper Types	Plain Paper, Photo Paper Plus Glossy II (PP-201), Photo Paper Pro Luster (LU-101), Photo Paper Plus Semi-gloss (SG-201), Matte Photo Paper (MP-101), Envelope
Paper Capacity	250 sheets
Paper Sizes	A4, A5, B5, Envelopes
