Canon PowerShot G16 User Manual

47
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode /
Hybrid Auto Mode
Other Shooting
Modes
Tv, Av, M, C1,
and C2 Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
P Mode
Helpful Shooting Features
Still Images Movies
Using the Dual Axis Electronic Level
An electronic level can be displayed as a guideline to ensure the camera is
level from front to back and left to right.
1 Display the electronic level.
 Press the <p> button several times to
display the electronic level.
2 Straighten the camera.
 If the camera is tilted, move it so that the
red line changes to green.
• If the electronic level is not displayed in step 1, press the <n> button, and
on the [4] tab, choose [Custom Display]. Add a [
] to [ ] or [ ] to choose
the electronic level.
• The electronic level is not displayed during movie recording.
• If you hold the camera vertically, the orientation of the electronic level will be
updated automatically to match the camera orientation.
• Calibrate the electronic level if it seems ineffective in helping you level the
camera (=
155).
Back or
Forward
Left or Right
Still Images
Magnifying the Area in Focus
You can check the focus by pressing the shutter button halfway, which will
enlarge the portion of the image in focus in the AF frame.
1 Congurethesetting.
 Press the <n> button, choose [AF-
Point Zoom] on the [4] tab, and then
choose [On] (=
25).
2 Check the focus.
 Press the shutter button halfway. The
face detected as the main subject is now
magnied.
 To restore the original setting, choose
[Off] in step 1.
• Theareainfocuswillnotbemagniedwhenyoupresstheshutter
button halfway if a face was not detected, if the person is too close
to the camera and their face is too large for the screen, or if the
camera detects subject movement.

Canon PowerShot G16 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.8 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 4:5, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	4000 x 2248, 2816 x 1584, 1920 x 1080, 640 x 360, 4000 x 2664, 2816 x 1880, 1600 x 1064, 640 x 424, 4000 x 3000, 2816 x 2112, 1600 x 1200, 640 x 480, 2992 x 2992, 2112 x 2112, 1200 x 1200, 480 x 480, 2400 x 3000, 1696 x 2112, 960 x 1200, 384 x 480
Digital zoom	4 x
Optical zoom	5 x
Combined zoom	20 x
Focal length range	6.1 - 30.5 mm
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	140 mm
Minimum focal length (35mm film equiv)	28 mm
Focus	TTL
Focus adjustment	Auto/Manual
Normal focusing range	0.05 - ∞ m
Auto focusing (AF) modes	-
Macro focusing range (wide)	0.01 - 0.5 m
Auto Mode focusing range (tele)	0.4 - ∞ m
Auto Mode focusing range (wide)	0.01 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 12800, Auto
Light exposure modes	Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	250 s
Flash modes	Auto, Flash off, Flash on, Slow synchronization
Flash range (tele)	0.5 - 4.5 m
Flash range (wide)	0.5 - 7 m
Flash recharging time	10 s
Flash exposure correction	±2EV (1/3 EV step)
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1920x1080@30fps, 1920x1080@60fps, 640x480@120fps, 640x480@30fps
Audio formats supported	LPCM
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	32 GB
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	922000 pixels
Viewfinder type	Optical
HDMI connector type	Mini
Scene modes	Fireworks, Night, Portrait, Snow, Underwater
Image editing	Rotating
Photo effects	Black&White, Neutral, Positive film, Sepia, Skin tones, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Fluorescent H, Tungsten, Underwater
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Movie, Single image, Slide show
Image processor	DIGIC 6
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HEB, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR, VIE
Battery type	NB-10L
Battery voltage	7.4 V
Battery capacity	920 mAh
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	40.3 mm
Width	108.8 mm
Height	75.9 mm
Weight	314 g
Weight (including battery)	356 g
