Canon PowerShot G16 User Manual

81
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode /
Hybrid Auto Mode
Other Shooting
Modes
Tv, Av, M, C1,
and C2 Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
P Mode
Still Images Movies
Changing the AF Frame Mode
Change the AF (auto focus) frame mode to suit the shooting conditions as
follows.
 Press the <n> button, choose [AF
Frame] on the [4] tab, and then choose
the desired option (=
25).
Still Images
FlexiZone/Center
One AF frame is displayed. Effective for reliable focusing.
With [FlexiZone], you can move and resize the AF frame (= 81).
• A yellow AF frame is displayed with [
] if the camera cannot focus
when you press the shutter button halfway.
• To compose shots so that subjects are positioned at the edge or in a corner,
rstaimthecameratocapturethesubjectinanAFframe,andthenhold
the shutter button halfway down. As you continue to hold the shutter button
halfway, recompose the shot as desired, and then press the shutter button all
the way down (Focus Lock).
Still Images
Moving and Resizing AF Frames (FlexiZone)
When you want to change the position or size of the AF frame, set the AF
frame mode to [FlexiZone] (= 81).
1 Prepare to move the AF frame.
 Press the < > button. The AF frame
turns orange.
2 Move and resize the AF frame.
 Turn the <7> dial to move the AF frame,
or press the <o><p><q><r> buttons
to move it by a smaller amount.
 To return the AF frame to the original
position in the center, keep the <
>
button held down.
 To reduce the AF frame size, press the
<n> button. Press it again to restore
it to the original size.
3 Finish the setup process.
 Press the < > button.

Canon PowerShot G16 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.8 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 4:5, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	4000 x 2248, 2816 x 1584, 1920 x 1080, 640 x 360, 4000 x 2664, 2816 x 1880, 1600 x 1064, 640 x 424, 4000 x 3000, 2816 x 2112, 1600 x 1200, 640 x 480, 2992 x 2992, 2112 x 2112, 1200 x 1200, 480 x 480, 2400 x 3000, 1696 x 2112, 960 x 1200, 384 x 480
Digital zoom	4 x
Optical zoom	5 x
Combined zoom	20 x
Focal length range	6.1 - 30.5 mm
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	140 mm
Minimum focal length (35mm film equiv)	28 mm
Focus	TTL
Focus adjustment	Auto/Manual
Normal focusing range	0.05 - ∞ m
Auto focusing (AF) modes	-
Macro focusing range (wide)	0.01 - 0.5 m
Auto Mode focusing range (tele)	0.4 - ∞ m
Auto Mode focusing range (wide)	0.01 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 12800, Auto
Light exposure modes	Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	250 s
Flash modes	Auto, Flash off, Flash on, Slow synchronization
Flash range (tele)	0.5 - 4.5 m
Flash range (wide)	0.5 - 7 m
Flash recharging time	10 s
Flash exposure correction	±2EV (1/3 EV step)
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1920x1080@30fps, 1920x1080@60fps, 640x480@120fps, 640x480@30fps
Audio formats supported	LPCM
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	32 GB
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	922000 pixels
Viewfinder type	Optical
HDMI connector type	Mini
Scene modes	Fireworks, Night, Portrait, Snow, Underwater
Image editing	Rotating
Photo effects	Black&White, Neutral, Positive film, Sepia, Skin tones, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Fluorescent H, Tungsten, Underwater
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Movie, Single image, Slide show
Image processor	DIGIC 6
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HEB, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR, VIE
Battery type	NB-10L
Battery voltage	7.4 V
Battery capacity	920 mAh
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	40.3 mm
Width	108.8 mm
Height	75.9 mm
Weight	314 g
Weight (including battery)	356 g
