Canon XF100 User Manual

6
121
External Connections
Video Output Configuration
The video signal output from the HD/SD SDI (b only), HDMI OUT and HD/SD COMPONENT OUT
terminals depends on the clip’s video configuration, the capability of the external monitor (for video output from
the HDMI OUT terminal) and on various menu settings. Video output from the AV terminal will always be in
576/50i standard.
Video Output Configuration by Terminal
Refer to the following table for the video output configuration from each terminal. If necessary, you can
superimpose the onscreen displays on the video displayed on the external monitor (0 125).
NOTES
• b When the camcorder is connected via HDMI OUT terminal to an external monitor, the video signal
output from the HD/SD SDI terminal will be the same as that from the HDMI OUT terminal.
Operating modes:
Video Output Configuration by Terminal
1
Set [N Video Setup] [SDI Output] to [HD], [SD] or [Off].
2
When you set [M LCD/VF Setup] [HD Output] (under [Zebra]) to [On], you can display zebra patterns on an external monitor.
In such case, output from the HD/SD SDI terminal (b only) and HD/SD COMPONENT OUT terminal will be in HD, regard-
less of their setting.
3
Video output will automatically switch to HD or SD, depending on the capability of the external monitor.
4
Set [N Video Setup] [Component Output] to [HD] or [SD].
5
When output from the HDMI OUT terminal is SD (576/50P), the output of the HD/SD SDI terminal will also be 576/50P.
Terminal J
HD/SD SDI
1, 2
(b only)
HDMI OUT
2, 3
HD/SD COMPONENT
OUT
2, 4
AV
Recording frame
size / Frame rate L
HD
output
SD
output
HD
output
SD
output
HD
output
SD
output
SD
output
1080/50i
1080/50i 576/50i
5
1080/50i 576/50P 1080/50i 576/50i 576/50i
1080/25P
1080/slow or
fast motion
720/50P
720/50P 576/50i
5
720/50P 576/50P 720/50P 576/50i 576/50i
720/25P
720/slow or
fast motion
COPY

Canon XF100 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	2.07 MP
Filter size	58 mm
Digital zoom	6 x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD, SDHC, SDXC
Maximum memory card size	32 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Scene modes	Backlight, Spotlight
Light exposure modes	Auto
Camera shutter speed	1/3 - 1/2000 s
Display diagonal	3.5 \
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Photo effects	Black&White
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	0.7 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	268 mm
Width	139 mm
Height	191 mm
Weight	1120 g
