Canon Xsi User Manual

Mounting and Detaching a Lens
34
To zoom, turn the zoom ring on the lens
with your fingers.
If you want to zoom, do it before
focusing. Turning the zoom ring after
achieving focus may throw off the
focus slightly.
While pressing the lens release
button, turn the lens as shown by
the arrow.
Turn the lens until it stops, then
detach it.
About Zooming
Detaching the Lens
Minimizing Dust
When changing lenses, do it in a place with minimal dust.
When storing the camera without a lens attached, be sure to attach the
body cap to the camera.
Remove dust on the body cap before attaching it.
Image Conversion Factor
Since the image size is smaller
than the 35mm film format, it will
look like the lens focal length is
increased by 1.6x.
Image size
(22.2 x 14.8mm / 0.87 x 0.58 in.)
35mm image size
(36 x 24mm / 1.42 x 0.94 in.)
H73_01.fm Page 34 Friday, December 14, 2007 3:24 PM

Canon Xsi Specifications

General

Model	EOS Rebel XSi / 450D
Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	22.2 x 14.8 mm
Effective Pixels	12.2 megapixels
ISO Range	100-1600
Autofocus Points	9
Shutter Speed Range	1/4000 to 30 sec
Continuous Shooting Speed	3.5 fps
LCD Screen Size	3.0 inches
LCD Screen Resolution	230, 000 dots
Viewfinder Type	Optical pentamirror
Viewfinder Coverage	95%
Max Video Resolution	No video recording
Storage Media	SD/SDHC card
Battery	LP-E5
Image Stabilization	Lens-based
Dimensions	128.8 x 97.5 x 61.9 mm
Weight	475 g (including battery)
