H Piquet
I
J
Clé hexagonale
Clé
A Boulon M6x10 8
180
16
8
28
20
20
8
2
1
B Boulon M6x15
C Boulon M6x40
D Boulon M6x55
E Écrou de 10 mm avec filetages M6
F Rondelle
G Cache-écrou
LISTE DU MATÉRIEL
DESCRIPTION ILLUSTRATION QUANTITÉ
QUINCAILLERIE
MATÉRIEL
RÉFÉRENCE
11
ABRI DE JARDIN SKYLINE À TOIT À UN NIVEAU, 10 x 10 PI
