ELECTRICAL CONNECTION:
NOTE:
The oven is fitted with a plug and must only be connected to a properly installed earthed socket.
The socket must only be installed and the connecting cable must only be replaced by a qualified
electrician, and in accordance with the appropriate regulations.
If the plug is not longer accessible following installation, an all-pole isolating switch must be
present on the installation side with a contact gap of at least 3mm.
WARNING:
Do not trap or bend power cable.
 
 
         
      
      
      
      
    
       
     
       
     
       
   
   
      


       
Installation Instructions
Please Read the Manual Carefully Before Installation
A gap must be maintained between
the wall and the base of the
unit above.
Specific
gap size
could be referenced by the diagrams.
Screw A
Trim-kit plastic cover
Bracket
12
Screw B
