Stainless Steel Plinth (Supplied separately)
When the wine cellar is installed in its final position, the stainless steel plinth should be
fitted. Remove the protective tape from the adhesive strips on the rear of the plinth and
then place firmly in position onto the bottom of the wine cellar cabinet.
THE FLOW OF AIR THROUGH THE GRILL MUST NOT BE OBSTRUCTED AT ANY
TIME. FAILURE TO ADHERE TO THIS WILL INVALIDATE THE GUARANTEE.
OPERATING INSTRUCTIONS
The wine cellar should be placed where the ambient temperature is between 0-35 deg
centigrade (32-95 degrees Fahrenheit). If the ambient temperature is above or below this
range, the performance of the unit may be affected. For example, placing your unit in
extreme cold or hot conditions may cause interior temperatures to fluctuate. The range of
5-18 ºC (40-65 degrees Fahrenheit) may not be reached.
Control Panel
• RUN
Indicator light illuminates to signify the cooling cycle is currently in operation.
• LIGHT SWITCH
To control the interior light, on/off.
• “UP” Button
To raise (warm) the temperature in 1 ºC stages.
• “DOWN” Button
To lower (cool) the temperature in 1 ºC stages.
Setting the Temperature Control
• You can set the temperature as you desire by pressing the UP or DOWN buttons. When
you press either of the two buttons for the first time, the LED readout will show the original
temperature set at previous time (the temperature preset at the factory is 12 ºC.
• The temperature that you desire to set will increase by 1ºC if you press the UP button
once, and will decrease 1ºC if you press the DOWN button once.
• The temperature selected will flash in the LED display for approximately 5 seconds, and
will then display the actual temperature (which will gradually reach the set temperature).
• To view the “set” temperature, press the UP or DOWN button, then the LED display will
“flash” for 5 seconds to show the “set” temperature.
